Axonal injury is detected by βAPP immunohistochemistry in rapid death from head injury following road traffic collision

The timing of traumatic brain injury, dependent on neuropathological examination, is one of the most challenging aspects of forensic neuropathology. It is a complex task and requires close interpretation and integration of a set of morphological and immunohistochemical tests together with other autopsy findings. For instance, the timing of intracranial haemorrhage (subdural or extradural haematoma) and contusions depends on assessing the extent of the reactive changes in the dura or brain, respectively, and the healing stages; including type of inflammatory cell infiltration (neutrophils and macrophages) in addition to changes such as the extent of necrosis and ischaemia in adjacent neural tissue.

Another level of timing of traumatic brain injury (TBI) depends on assessing the morphological representation of the axonal injury via demonstration of axonal injury by H&E stain, silver stain, and more time-accurately, by immunostaining for βAPP [1‐7]. βAPP is a ubiquitous membrane glycoprotein produced in the cell body and plays a physiological role in cell adhesion and endogenous neuroprotection in response to injury (4, 8). It is transported by fast axoplasmic transport and accumulates proximal to the site of axonal injury [4, 5].The predominant mechanism in developing axonal injury in TBI is mechanical shearing and stretch forces produced by inertial acceleration/deceleration stresses to the head. This inertial loading triggers dynamic shear tensile and compressive strain within the brain [9‐12]. Consequently, certain parts of the brain move at a slower pace relative to others, leading to deformation of brain tissue, putting long-tract structures such as axons and blood vessels at risk of shear injuries [13, 14]. The distortion of the axonal cytoskeleton subsequently disturbs the normal axonal transport leading to accumulation of transported axonal products in the injured region and alteration of neuronal homeostasis [15, 16]. Therefore, detection of βAPP by immunohistochemistry is indicative of disruption of axonal transport but it is not entirely specific for the cause of this disruption which could, for example, be due to trauma, ischaemia, infection or drug overdose [17‐19].

BAPP accumulation is an active energy-dependent process requiring blood circulation and therefore is closely related to the patient’s post-incident survival time [20, 21]. The earliest time in which axonal injury has been reported to be detected by immunohistochemistry in autopsy brain examination is 35 min after traumatic brain injury [7, 20]. The amount of accumulated βAPP increases with the time of survival post-axonal injury, becoming easily and more frequently detected after about one hour and reaching its maximum intensity and frequency at around 24 h after head injury [3]. It is reported that there may be a correlation between the size of the accumulated βAPP immunoreactivity and period of survival, but this doesn’t enable precise timing of injury despite using morphometrical assessments of the size of the accumulated protein [6]. After 24 h, the staining of the βAPP starts to fade, appearing as faint accumulation and acquiring a more granular pattern with the passage of time. Ultimately it disappears from the site of axonal injury after 30 days leaving faint granular deposits in glial cells [2]. The activation of microglia cells at the site of axonal injury is another useful tool in timing of TBI. Microglial cells can become activated at the site of the axonal injury clearly at around 36–48 h and can be useful in timing axonal injury when closely correlated with the site of axonal injury as detected with βAPP [22, 23].

Within our forensic neuropathology practice, we observed a few cases of head injury with βAPP immune reactivity in which the survival time is reported to be less than 30 min and in others with rapid and near instantaneous death. The question has thus arisen as to what is the possible minimum post-incident time of survival that axonal injury can be detected by βAPP immunohistochemistry. This is an important question in medico-legal practice for the diagnosis of traumatic brain injury in patients who died instantaneously/rapidly after head injury and also would shed light on the pathophysiology of axonal injury in severe head trauma.

The aim of this work was to investigate if βAPP staining for axonal injury can be detected in the autopsy brain in patients with rapid death following fatal RTC. By answering this question, the study provides further insight into the rapidity which βAPP can be demonstrated after fatal head injury and may provide further understanding into the pathophysiology of axonal injury.

In all the cases, the brains were examined by one of the authors who is a senior forensic pathologist (GR) as part of the police and coronial examination. A standardized examination and sampling protocol was undertaken in each case. The brains were dissected at the time of autopsy examination by cutting into coronal sections of 1 cm thickness. The slices were closely examined according to the anatomical regions and then a full set of tissue blocks taken for histology, including two sections of cerebral cortex and white matter from central semi ovale, two levels from corpus callosum, basal ganglia including internal capsule, cerebellum (and its white matter) and brainstem including midbrain and pons (total 9 tissue blocks) [24].

Forty-nine cases were recruited into the study; 48 had died following a road traffic collision and one following a single occupancy air crash. These are divided to three groups (the results are summarized in Table 2):

The previous work by Hortobagyi et al., 2007 had provided evidence that using βAPP immunohistochemistry can detect axonal damage within 35 min after severe head injury [20]. In the current study however, we are able to demonstrate that in fact axonal injury can be detected earlier than this time with βAPP staining in patients who died rapidly at the scene of an RTC (i.e., in a few to several minutes but less than 30 minutes after the accident). This is an interesting and important finding of medicolegal importance, which is useful in the diagnosis of head injury with very short survival time.

Another important point of difference is that Hortobagyi et al. studied only seven cases of head injuries resulting from assaults [20], while our study involved a larger number of fatal head injuries resulting from RTC. Therefore, another possible explanation as to why we were able to detect βAPP in shorter survival times is that our cases represented a different cohort of more severe head injury resulting from RTC. It is expected that the magnitude of the force in RTCs and the severity of acceleration and deceleration of the brain tissue would be more severe compared with those resulting from assault [8, 25‐28]. This issue can be further clarified with an understanding of the pathophysiology of the axonal injury and the physiological function of βAPP and in appreciating the heterogeneous types of TBI and its different effects on varying brain regions.

There are also technical differences between the previous of Hortobagyi et al. and the current work regarding the detection of βAPP. We used a different antibody with a well-calibrated dilution and standardized staining using an auto-stainer, compared with previously used manual methods. Although it is possible that these technical differences could have improved the ability to detect βAPP, we believe they have minimal effect on overall results compared with the other factors such as the nature of the different cohort of head injury cases mentioned above.

It has become clear that traumatic axonal damage is common in all degrees of head injuries but the severity varies in different cases depending on the load of force and degree of acceleration and deceleration of the brain—which are directly related to the mechanically altered axons [29].

At one end of the spectrum, in mild-to-moderate head injury there may be mild-or-temporary transmembrane ionic disturbance of axons which could be reversible. This form of axonal injury is characterized by increased axolemmal permeability, mitochondrial swelling and cytoskeletal compaction disturbing the microtubules and neurofilament structure [30, 31]. The mild-to-moderate axonal injury is not necessarily associated with axonal transection but may cause reverse axonal transport which has been considered as a possible mechanism for accumulation of the transported axonal products, including βAPP [32].

At the other end of the spectrum is severe head injury, causing immediate primary axotomy or marked disruption of the axonal cytoskeleton ending in secondary axotomy. In the injured axon, the increase in the permeability of axolemma is more significant and causes more marked alterations in transmembrane ion concertation accompanied by fluid entry to axons leading to axonal swelling [33, 34]. With more severe injury, the extent of intercellular Ca ion accumulation leads to proteolysis, rapid compaction of neurofilaments and later collapse of the cytoskeleton [35, 36]. If the cytoskeleton cannot remodel itself, then delayed secondary axotomy will eventually occur leading to irreversible damage. This is an active energy-dependent process and may take a few minutes to several hours if the patient survives, depending on the magnitude of the loaded forces and the type of axons and location. This form of secondary delayed axonopathy that occurs subsequent to traumas had been characterized by progression of the formation of axonal balls and varicosities thought to be within one hour after injuries with disconnection by about 6 to 12 h and which can be easily detected by immunoreactivity of βAPP [37]. In cases of very severe head injury such as those resulting from RTC, the shearing of the axonal fibers leads to complete disconnection in a process of primary axotomy. However, despite the apparent correlation between the magnitude of the head injury and the traumatic axonal injury, primary axotomy is thought to be a minor contributor compared with the secondary mechanism in overall axonopathy seen in TBI [34, 35]. Nevertheless, it is still possible that very severe head injury, such as those caused by RTC, may cause a significant axonal injury and rapid accumulation of the transported products in the injured axons, including the ΒAPP, leading to the formation of the small individually well-defined swellings as seen in our cases. These most likely represent morphologically normal but functionally incapacitated axons with disruption of normal axoplasmic flow [38].

In few cases of group 1, the death is expected to be very rapid such as case number 10 in which the death had resulted from severe polytrauma including severe head injuries with multiple skull fractures resulted from a fatal airplane crash. Despite the expected very rapid death, there are infrequent βAPP immunoreactive foci in the cerebral white matter, corpus callosum and cerebellar white matter which suggest that βAPP can be accumulated in tiny amount even with low level of blood circulation in such conditions considering the fact that βAPP is active energy-dependent process.

Further support for our suggestion comes from in vitro and animal studies: In vitro studies using neuronal preparations reveal that immediately subsequent to stretch injuries the axonal structure is distorted, and some axons become undulated and twisted due to cytoskeletal damage. The internodal regions of the axons appear to be particularly vulnerable, whether due to specific mechanical features of this region or lack of association with supportive astrocytes. The changes in the cytoskeleton and neurofilament structure had been detected within 15 min after injury with subsequent disruption of the axonal transport and accumulation of the transport product [28, 39, 40].

Although animal models may not exactly replicate the reaction to traumatic axonal injury, they are useful to shed light on the mechanism and timing of damage. These models demonstrate ultra-structural changes detectable within few minutes of injury. These include mitochondrial swellings followed by misalignment of microtubules which inevitably leads to distortion of ante-grade and retro grade axonal flow interfering with normal transport of products down the axons [28, 41].

We consider the possibility that some of the axonal disruption in group 1 patients may be present prior the RTC such as that caused by alcohol, drug overdose or aging but we believe this possibility is less likely (although cannot be completely excluded) because the pattern and intensity of the βAPP would be seen as more intense, widespread ill-defined granular deposits—different from the described pattern in group 1. This is well demonstrated in the control brain of age 72 years (case number 5 of group 4 in Table 2). There is one small globule in the white matter with faint and granular staining ( Fig. 5) which is different from the more densely stained small globule seen in group 1 cases.

We propose that if the head injury is severe, like those in severe and fatal impact injury, one would expect a severe and rapid axonal damage, probably more frequent primary axotomy or a very rapid secondary axotomy occurring in minutes. The neurofilament backbone of the axons quickly collapses, leading to disintegration at the site of the damage. Following this, the axolemma beginnings to fold inward and separate from the underlying myelin sheath. The transported proteins continue down the stream of the axoplasm until they reach the site of injury where they immediately accumulate because they are unable to progress. This is the point when βAPP is expected to be visible as small well-defined globules or thin filaments.

Another possible explanation as to why βAPP can identify the site of axonal damage so early after trauma may be based on the function of the βAPP protein as a rapid post-traumatic inflammatory and neuroprotective response. TBI is an intrinsically heterogeneous process that does not occur in vacuum. It in fact causes multiple cascades of events involving upregulation of oxidative, excitoxic and inflammatory pathways that affect the evolution of axonal pathology [42, 43]. βAPP is a ubiquitous membrane glycoprotein produced in the cell body and it is transported in vesicles by fast anterograde axoplasmic transport as it has synaptic function. It plays a physiological role in cell adhesion, functions as a contact receptor, synaptic modification and endogenous neuroprotection in response to injury such as against ischaemia and excitotoxic injury [21, 44]. Its activation and overexpression may be part of an immediate inflammatory neuro-protection response to injury together with many other factors [21, 45]. One of these factors is clusterin which is specifically explored by Troakes et al., in cases of head injury [46]. Clusterin is also known as apolipoprotein J (ApoJ), a highly conserved ubiquitous glycoprotein in the brain. It is a stress-induced chaperone which is normally secreted; however, in conditions of cellular stress it can be transported to the cytoplasm where it binds to Bax protein and inhibits neuronal apoptosis [47]. Additionally, clusterin is a well-known complement inhibitor, binding to C5b-9 component and inhibiting the formation and membrane binding of MAC (membrane attack complex) [48, 49].

Troakes et al. have shown that clusterin is over-expressed very soon after the onset of TBI, suggesting that it plays a role in the response to blunt trauma and that it may assist in remodeling and modulation of the inflammatory response following this form of brain injury. They also demonstrated that staining of clusterin was closely associated with βAPP accumulation when examined by double immunofluorescence in white matter, which is consistent with overexpression at the site of axonal injury and dysfunction. Clusterin was observed deposited in the white matter of brains from patients who died from head injury in less than 30 min after the initial injury, although as previously mentioned it is quite possible that death could have occurred even earlier and that clusterin is deposited extremely rapidly after TBI [46].

If the severe head injury in RTC can cause marked and widespread mechanical stress and expected widespread axonal injury, then why does the immunohistochemical staining with βAPP only reveal infrequent and scattered sites of axonopathy? One explanation is that the myelination varies between neighboring axons and that finely myelinated small axons appear more vulnerable to injury [28]. It is therefore likely that the visible microscopic findings of BAPP accumulation underestimate the extent of injury in the neighboring fibers with varying degree of injury as the proportion of histologically abnormal axons seen in trauma models and patients is inconsistent with the magnitude of the TBI. Another possibility is that the mechanical load of the transmitted forces is variable throughout the brain regions and may have variable effect on different types of axons (diameter, length and myelination) leading to different spectrum of changes in different brain regions.

As mentioned earlier, the very early accumulation of BAPP in axonal injury in patients who died at the scene of an RTC indicates interruption of the fast-axonal transport and not necessarily axotomy. Some βAPP may accumulate due to temporary and reversible axonal dysfunction [3]. Therefore, from a practical point of view, it may not be possible to know the significance of this accumulation in relation to the degree of head injury. However, the involvement of infra tentorial parts of the brain including the cerebellum, cerebellar peduncles and brain stem structure in additions to the supra tentorial parts would raise possibility of a severe degree of head injury [3, 20]. Nevertheless, care should be taking not to over interpret the small amounts of βAPP accumulation in rapid death after head trauma without other evidence of severe head injury. Another note of caution in the same issue is to consider the possibility of an ischaemic disruption of axons accompanying the head injury [19, 50]. The ischaemia in the context of RTCs is frequent resulting from reduction of the cerebral blood flow due to other systemic injuries and blood loss. In our cohort of RTC, the ischaemia could have a contribution to the axonal injuries and accumulation of βAPP but this is extremely difficult to ascertain or disprove in this work which actually aimed to investigate the timing of the axonal injury due to head injury or its consequent ischaemia.

There is no data as to when βAPP accumulation may be expected to appear in ischaemia alone. One would expect it to be of similar timing to those of trauma but this is not necessarily true. Ischaemia is not expected to cause primary axotomy or rapid disruption to the axonal cytoskeleton as seen with trauma, therefore it is less likely to cause such rapid accumulation of βAPP [19].

The progression and evolution of the axonal injury reflected by the shape and the frequency and intensity of βAPP accumulation after hours and days survival time (group 2 and 3) is well demonstrated in this and confirms the findings in previous studies. We found the amount and frequency of staining of βAPP in head injuries increases with the increasing time of survival of the victim and increased intensity reflecting larger amounts of accumulated protein in group 2 and group 3. When patients survived a few days, the intensity became less and the βAPP staining became faintly granular, almost disappearing after one-month survival (case number 45).

Axonal injury can be detected in the brain of those who died rapidly following fatal road traffic collision. We propose that the early accumulation of βAPP is probably due to the high magnitude of loaded forces in head injury resulting from RTC in this cohort which could possibly cause higher proportions of primary axotomies and/or that the stretching axonal injuries are more severe, causing quicker alteration in the axonal cytoskeleton. Our result is expected to have implications on the timing of head injuries in medicolegal practice but caution is recommended so as not to over-interpret the results which require close correlation with autopsy findings, circumstance of the incidence, and other investigations.
