Diagnosis and Reporting of Follicular-Patterned Thyroid Lesions by Fine Needle Aspiration

The application of FNA to distinguish benign follicular nodules from follicular carcinomas is problematic because the criteria for distinguishing between them are based upon histologic evidence of transcapsular or vascular invasion. Since invasion cannot be assessed by FNA, the question becomes “how can FNA be used to evaluate follicular neoplasia.” The answer is that FNA is used as a screening test for follicular carcinoma. The cytologic criteria used to distinguish benign from suspicious thyroid lesions includes the follicular group architecture, smear cellularity, amount of colloid, and cytologic atypia [8]. By far, the most important of these criteria is cytoarchitecture [9, 10]. Thus, while a specific diagnosis may not be given, it is possible to subcategorize these lesions into two groups: those which are almost certainly benign, and those which are suspicious for a follicular neoplasm and possibly malignant. This subcategorization identifies a majority of patients with benign lesions for whom surgical intervention can usually be avoided.

Benign thyroid nodules are characterized microscopically by a macrofollicular pattern which features large flat sheets of follicular cells with small dark round nuclei in a honeycomb arrangement, usually in a background of moderate to abundant colloid (Fig. 1). The flat sheets of cells result from fragmentation of macrofollicles with extrusion of colloid during the smear preparation. In contrast, thyroid aspirates composed of microfollicles (small follicular groups of 6–12 follicular cells in a ring with or without a small amount of central colloid), crowded trabeculae, or 3-D groups of overlapping follicular cells are a feature of follicular carcinomas as well as some adenomas (Fig. 2). These aspirates are diagnosed as “suspicious for a follicular neoplasm,” and it is this group of patients for whom thyroid lobectomy is generally considered warranted.

Bild vergrößern

Bild vergrößern

By sorting follicular lesions into two groups based primarily upon cytoarchitecture, FNA can identify a large subset of nodules that are benign, and that do not require surgery. This approach works because follicular carcinomas are rarely composed of predominantly normal-sized or macrofollicles [8, 10]. The key to using this approach is to focus upon the predominant cytoarchitectural pattern. A common pitfall is to identify a minor population of microfollicles and ignore the overall pattern. In addition, it is important to also evaluate the nuclear features of the cells to avoid the pitfall of the follicular variant of papillary thyroid carcinoma.

Unfortunately, while FNA as a screening test is highly sensitive, it lacks specificity. Approximately 15–30% of aspirates diagnosed as “suspicious for a follicular neoplasm” are actually carcinomas while the remaining 70–85% of nodules are benign. [11‐13] A wide variety of immunohistochemical and molecular markers have been studied in an attempt to distinguish between benign thyroid nodules and follicular carcinomas in FNA samples; however, to date, none has been identified with both high sensitivity and specificity. Until such marker is available, FNA will remain a screening test rather than a diagnostic test for follicular carcinomas.

The follicular variant of papillary thyroid carcinoma is the most common subtype of papillary thyroid carcinomas [5]. In FNA specimens, it can pose a diagnostic challenge due to the abundance of microfollicles or monolayer tissue fragments mimicking a follicular neoplasm. In fact, among those FNAs diagnosed as “suspicious for a follicular neoplasm” that are malignant in histologic follow-up, over 30% are identified as the follicular variant of papillary thyroid carcinoma [13, 14]. In contrast to the hyperchromatic chromatin seen in follicular neoplasms, the follicular variant of papillary thyroid carcinoma exhibits pale, powdery chromatin along with nuclear grooves and occasional intranuclear pseudoinclusions (Fig. 3). The cells tend to be round to oval and less pleomorphic than the conventional type of papillary carcinoma. Variable amounts of dense colloid are frequently seen in this variant, and multinucleated giant cells may also be identified. Usually the cytologic diagnosis of the follicular variant of papillary carcinoma is not difficult, but in a subset of cases, the nuclear features can be quite subtle resulting in misclassification of the lesion. Development of methods to detect RET/PTC rearrangements or point mutations of the BRAF gene in routine thyroid FNA samples may prove useful for solving this problem [15].

Bild vergrößern

A major challenge in the application of FNA to the diagnosis of thyroid lesions has been the inconsistent use of terminology for reporting results of thyroid FNAs both within laboratories and between different institutions. Not only has this hindered the sharing of information between different institutions, but it has created difficulties for clinicians managing patients with thyroid disease. A major advance on this front was made by the NCI Thyroid FNA State of the Science Conference which convened on October 22–23, 2007 in Bethesda, Maryland. It addressed issues including indications for thyroid FNA, training, techniques, reporting terminology, ancillary testing, and management guidelines [16, 17]. Based upon the findings, a Bethesda System-type diagnostic framework for reporting thyroid FNA results was proposed that consists of seven general diagnostic categories (Table 1). Importantly, the terms used for reporting results are associated with a risk of malignancy which will impact recommendations for patient management [16].

While most follicular-patterned lesions can be accurately assessed using thyroid FNA, a small subset of lesions exhibit cytologic features that are intermediate between benign and neoplastic. This so-called “indeterminate” category has been used in various ways by different laboratories. Some have used this category for any aspirate with atypia, for others the category has been used to mean “indeterminate for malignancy” or “indeterminate for neoplasia.” In the proposed Bethesda System for thyroid cytology, the ACUS or indeterminate category is specifically designated for use when the ‘cytologic and/or architectural atypia encountered is of uncertain significance: it is of an insufficient degree to qualify for any of the suspicious or malignant categories’ [18]. At the same time, the cytologic or architectural atypia is more than would be acceptable within the “benign” category. There are many different situations in which an ACUS diagnosis would be used, but some of the most common include the following: (1) a sparsely cellular aspirate with a predominance of microfollicles, (2) cytologic atypia in the setting of preparation artifact, (3) a mixed cytoarchitectural pattern that includes nearly equal proportions of macrofollicles and microfollicles (Fig. 4), (4) focal atypia suggestive of papillary carcinoma in an otherwise predominantly benign-appearing sample (Fig. 5). Because of the potential to overuse the ACUS category, it should be less than 7% of all thyroid FNA interpretations [18]. For thyroid aspirates diagnosed as ACUS, the recommended management is clinicoradiologic correlation and in most cases, a repeat FNA. The latter will often result in a more definitive “benign,” “suspicious,” or “malignant” designation; however, 20–25% of cases will result in a second ACUS diagnosis [13, 18]. The risk of malignancy for an ACUS diagnosis is difficult to assess because only a subset of ACUS nodules will be surgically excised. However, it is estimated that the overall risk of malignancy will be approximately 5–10% which is intermediate between the “benign” and “suspicious for a follicular neoplasm” categories [18].

Bild vergrößern

Bild vergrößern
