Extra-osseous Roles of the RANK-RANKL-OPG Axis with a Focus on Skeletal Muscle
- Open Access
- 26.09.2024
- REVIEW
Abstract
Introduction
Observed Effects of RANK-RANKL-OPG Modifications on Muscle Mass and Performance
Clinical Observations
Title, author, date, reference | Study parameters | Major findings |
|---|---|---|
Denosumab for prevention of fractures in postmenopausal women with osteoporosis Cummings et al., 2009 [13] | Postmenopausal women were treated with either placebo (N = 3906) or denosumab (DMab) 60mg (N = 3902) every 6 months for 3 years | > Denosumab treatment for 3 years was associated with a significant reduction in falls (adverse events), when compared to placebo group (p = 0.02) |
Treatment of facioscapulohumeral muscular dystrophy with Denosumab Lefkowitz, Lefkowitz and Kethley, 2012 [24] | Case study: 66-year-old female (diagnosed with facioscapulohumeral muscular dystrophy and osteoporosis). Treated with DMab 60mg. Second injection given 63 days after the first. A total of seven injections were given (with 40–42-day intervals post second injection) | > Drastic reversal of dystrophic symptoms was observed after every DMab injection. Reversal of beneficial effects initiated around 6–7 weeks post DMab injection > 24 h after 1st injection: Subject was able to walk without a cane, bury her eyelashes, swallow easier, open bottles (was unable to do prior to the DMab injection), and was physically stronger and exhibited improved balance > 24 h after 2nd injection: Subject was able to whistle, walk in high heels, snap her fingers, and play the piano without fatigue (amongst other, not listed improvements). Significant improvements in hand grip strength, get up and go test and sit to stand test > 24 h after 3rd injection: Further significant improvements in hand grip strength, get up and go test and sit to stand test |
RANKL inhibition improves muscle strength and insulin sensitivity and restores bone mass. Bonnet et al., 2019 [22] | PMO women treated with DMab (N = 18, 65 ± 1.5 years), bisphosphonates (zoledronate N = 12, alendronate N = 8, 65.7 ± 0.9 years) or vehicle (N = 55, 65 ± 1.4 years). The groups were matched for age, BMI, BMD and fracture prevalence at baseline | > In PMO women, 3 years of DMab treatment improved appendicular lean mass and handgrip strength compared to no treatment, whereas bisphosphonates did not > Muscle parameters strongly correlated with changes in lumbar spine BMD |
Effect of Denosumab on Falls, Muscle Strength, and Function in Community‐Dwelling Older Adults. Phu et al., 2019 [21] | Longitudinal study (6 month) on the effects of DMab (N = 51) or zoldronate (N = 28) on muscle function of community-dwelling older adults | > DMab significantly improved gait speed whilst also enhancing multidirectional agility > Similar effects were seen in subjects receiving zoledronate, but DMab treatment was associated with greater improvements in the four-square step test and in a subjective measure for fear of falling |
A Pooled Analysis of Fall Incidence From Placebo-controlled Trials of Denosumab Chotiyarnwong et al., 2020 [16] | Meta-analysis of 5 placebo-controlled trials of DMab. Pooled characteristics: placebo N = 5006, 71.9 ± 6.9 years; DMab N = 5030, 71.8 ± 6.8 years (83.1% female) | > Estimated Kaplan–Meier incidence of falls was significantly higher in the placebo groups (6.5%), compared to DMab groups (5.2%) (p = 0.0061) > DMab treated subjects aged < 75 years were 35% less likely to fall versus matched controls |
Is there a potential dual effect of denosumab for treatment of osteoporosis and sarcopenia? Miedany et al., 2021 [33] | A longitudinal multicenter, controlled, prospective study. Study group: DMab (primary or combinatorial) treatment for postmenopausal/senile osteoporosis (N = 135, 5 years). Control group: treat-to-target, including zoledronate (N = 136, 3 years) and alendronate (N = 136, 5 years). 1st osteoporotic and sarcopenic assessment after 3–5 years of treatment, 2nd assessment after 1 year stopping osteoporosis therapy | > Upon completing DMab therapy (5 years), there was significant decrease in falls risk (p = 0.001) and significant improvements in all sarcopenia measures (grip strength, timed up and go and 4m walk, p = 0.01). One-year post-discontinuation of DMab, a significant worsening of both sarcopenia measures and falls risk (p = 0.01) was noted |
Beneficial effects of denosumab on muscle performance in patients with low BMD: a retrospective, propensity score-matched study. Rupp et al., 2022 [23] | Retrospective, propensity score-matched (sex, age, BMI, follow-up time) cohort study. 150 patients with osteopenia or osteoporosis receiving vitamin D (N = 60), bisphosphonates (N = 30) or DMab (N = 60) therapy. Mean follow up: 17.6 ± 9 months | > DMab (p < 0.001) and bisphosphonate (p = 0.001) treatments significantly increased grip force compared to vitamin D. DMab group significantly increased chair rising test force compared to the bisphosphonate group. Neither the changes in bone metabolic parameters nor BMD were associated with changes in muscle performance |
RANKL Blockade Reduces Cachexia and Bone Loss Induced by Non‐Metastatic Ovarian Cancer in Mice. Pin et al., 2022 [34] | Female adults with ovarian cancer assessed (cachexia N = 8, control N = 19) | > Human ovarian cancer is associated with elevated RANKL, cachexia, and bone loss |
Preclinical Observations
Title, author, date, reference | Study parameters | Major findings |
|---|---|---|
Osteoprotegerin protects against muscular dystrophy Dufresne et al., 2015 [15] | Determining OPG and RANKL release from LPS (1 μg/ml) stimulated C2C12 myotubes. 5-day differentiation protocol | > LPS stimulated myotube OPG release (significant increase after 16 h, ~ 800 pg/ml) > S-RANKL protein was undetectable in the C2C12 culture media after LPS stimulation |
Muscle RANK is a key regulator of Ca2+ storage, SERCA activity, and function of fast-twitch skeletal muscles. Dufresne et al., 2016 [36] | Characterising C2C12 myotubes (after 5 days of differentiation) | > RANK was undetectable in proliferating C2C12 myoblasts > C2C12 myotubes express RANK |
Angiogenin and Osteoprotegerin are type II muscle specific myokines protecting pancreatic beta-cells against pro-inflammatory cytokines. Rutti et al., 2018 [43] | Characterising primary human myoblasts sourced from either the soleus or triceps brachii (donors age: 22.79 ± 0.38), and the effects of conditioned media on beta cells | > Cultured differentiated primary human triceps brachii skeletal muscle cells secreted significantly more OPG compared to soleus muscle cells. 24 h of 20ng/ml TNF-α exposure significantly increased OPG levels in human triceps myotubes, compared to no TNF-α treatment > OPG counteracts the negative effects of conditioned medium from soleus skeletal muscle cells on primary pancreatic beta-cells proliferation and insulin secretion |
RANKL inhibition improves muscle strength and insulin sensitivity and restores bone mass. Bonnet et al., 2019 [22] | C2C12s ± chronic RANKL ± OPG-Fc | > In C2C12s, OPG-Fc reversed the effects of chronic RANKL exposure by blocking NF-κB signalling (as shown by reduced Fos, Jun and NFAT expression) > Chronic insulin exposure plus OPG-Fc treatment to C2C12s increased Glut-1, Glut-4, and Fabp4 gene expression, limited the phosphorylation of IRS1-Ser318 and decreased glucose levels (compared to chronic insulin exposure alone) |
Muscle weakness and selective muscle atrophy in osteoprotegerin-deficient mice. Hamoudi et al., 2020 [35] | C2C12 myotubes ± RANKL 100 ng/ml (for up to 48 h) | > C2C12 myotubes exposed to RANKL had significantly lower myotube CSA and significantly increased p-NFκB-p65 (after 15 min), Atrogin-1 (after 1 h) and MuRF-1 (after 6 h) protein expression |
Testing the efficacy of a human full-length OPG-Fc analog in a severe model of cardiotoxin-induced skeletal muscle injury and repair. Bouredji et al., 2021 [37] | C2C12s ± hFL-OPG-Fc 50–1000 ng/ml (4 days of differentiation, followed by 24-72 h of treatment). For CTX investigations, cells were exposed to CTX (1 μM) for 1 h | > 200–1000 ng/ml hFL-OPG-Fc significantly increased C2C12 fiber diameter (after 24 h) and 1000 ng/ml significantly increased C2C12 fusion index (after 72 h) > hFL-OPG-Fc treatment attenuated CTX-induced cytotoxicity in vitro, as shown by a reduction in lactate dehydrogenase, creatine kinase, cleaved-caspase 3, Bax and TUNEL+ apoptotic cells, and an increase in β3 integrin |
RANKL Mediates Muscle Atrophy and Dysfunction in a Cigarette Smoke-induced Model of Chronic Obstructive Pulmonary Disease. Xiong et al., 2021 [38] | C2C12s ± RANK-siRNA ± recombinant murine RANKL 10–200 ng/ml. 5-day differentiation protocol, treatment times varied between 30 min – 48 h | > In C2C12 myotubes, RANKL treatment significantly reduced, viability, FoxO3a ratio and MyHC expression and significantly increased the NF-κB-p65 ratio and Atrogin-1 and MuRF1 > RANK-siRNA kept Atrogin-1, MuRF1 and NF-κB-p65 ratio levels close to baseline in C2C12 myotubes, and significantly reduced the expression levels of these when treated with RANKL |
RANKL Blockade Reduces Cachexia and Bone Loss Induced by Non‐Metastatic Ovarian Cancer in Mice. Pin et al., 2022 [34] | C2C12 and human skeletal muscle myotubes ± RANKL (200 ng/ml) for 48 h. C2C12 myotubes and ES-2 co-culture ± anti-RANKL (CD254) for 48 h. 5-day differentiation protocol | > RANKL treatment significantly reduced C2C12 and human myotube fiber diameter > Anti-RANKL reduced C2C12 myotube atrophy induced by ES-2 (ovary cancer) cells |
Delayed denervation-induced muscle atrophy in Opg knockout mice. Zhang et al., 2023 [41] | Characterisation of isolated satellite cells (± differentiation protocols) from Opg −/− and WT 6-week-old male mice | > Satellite cells isolated from Opg −/− mice exhibited reduced proliferation but increased differentiation index and fusion index once differentiated for 48 h (when compared to WT) > Tet2 expression increased in differentiated satellite cells isolated from Opg −/− mice (when compared to WT) |
RANKL signaling drives skeletal muscle into the oxidative profile. Cavalcanti de Araújo et al., 2024 [42] | Mitochondrial function was explored in C2C12 myotubes ± 20 ng/ml RANKL. 5-day differentiation protocol | > After 15 min of RANKL exposure, C2C12 myotubes showed significant increases in phospho-ERK/total ERK and phospho-p38/total p38 ratios > RANKL treatment (24 h) significantly increased mitochondrial area, mtDNA/nDNA ratio and expression of citrate synthase, ATP-synthase, and NRF-1, a p38 MAPK inhibitor (SB203580) and MEK inhibitor (U0126) ameliorated these effects > C2C12 myotubes exhibited significant reductions in PTPRG and MuRF1 gene expression and increased spare respiratory capacity after 24 h of RANKL treatment |
Title, author, date, reference | Study parameters | Major findings |
|---|---|---|
Systemic cytokine response following exercise-induced muscle damage in humans Philippou et al., 2009 [44] | Young males (N = 10) performed quadricep eccentric exercises. Blood samples were obtained before exercise and 6 h, 2 days, 5 days and 16 days post-exercise | > Up to 2 days post exercise OPG and IL-6 concentrations were increased, and RANKL was decreased. Indication of a common modulating role of IL-6 and the OPG/RANKL system during skeletal muscle regeneration following damage |
*Osteoprotegerin protects against muscular dystrophy Dufresne et al., 2015 [15] | Assessment of mdx dystrophic mice (C57BL/10ScSn-Dmdmdx/J) – daily intraperitoneal injection of PBS or OPG-Fc (0.3 or 1 mg/kg/day) for 10 days (days 25 to 35 after birth) | > 0.3 mg/kg OPG-Fc significantly increased maximal specific force of mdx soleus (46%) and mdx EDL (114%) > 1 mg/kg OPG-Fc significantly increased maximal specific force of mdx soleus (70%), mdx EDL (223%) and mdx diaphragm (59%) muscles, and reduced muscle damage and macrophage (47%) and neutrophil (68%) infiltration of mdx EDL muscles |
Muscle RANK is a key regulator of Ca2+ storage, SERCA activity, and function of fast-twitch skeletal muscles. Dufresne et al., 2016 [36] | Muscle mass and functionality of RANKmko mice (specific RANK skeletal muscle deletion). Sciatic denervation was performed on adult mice aged 12-18 weeks. | > Denervated EDL muscles from RANKmko mice exhibited reduced mass, almost absent slow-twitch fibers and an increase in the proportion of fast-twitch fibers (IIA, IIB, IIX), whilst preserving the specific force tension. > Sham and denervated RANKmko soleus and EDL muscles exhibited a lower proportion of fast-twitch fibers expressing SERCA-1a and a higher proportion of fast twitch fibers expressing SERCA-2a. |
*Genetic deletion of muscle RANK or selective inhibition of RANKL is not as effective as full-length OPG-fc in mitigating muscular dystrophy. Dufresne et al., 2018 [40] | RANKmko mice (specific RANK skeletal muscle deletion) and mdx mice were used and cross bred (generating double deficient mice—dystrophin and RANK) mdx mice and cross breeds received intraperitoneal injections of: PBS, full-length OPG-Fc, truncated OPG-Fc (1 mg/kg/d), anti-RANKL (1 mg/kg/3d, IK22–5) or anti-TRAIL (1 mg/kg/3d, H2B2). Mice were treated for 10 days (day 25 to 35 post-birth) Functional performance assessment: 5–6-month-old mdx mice treated with vehicle (PBS) or full-length OPG-Fc (1 mg/kg/d) for 10 days (prior downhill running) | > RANK mRNA was 5.5-fold higher in mdx EDL muscles relative to C57BL/6 mice > Compared to PBS treated mdx control mice, maximum specific force was significantly higher in mdx mice treated with full-length OPG-Fc (soleus, EDL [restored to similar force level of WT] and diaphragm) and mdx-RANKmko mice (EDL and diaphragm) > mdx-RANKmko mice treated with full-length OPG-Fc exhibited significantly higher maximum specific force (compared to control); much higher than untreated mdx-RANKmko mice, indicating OPG may work independently to the RANK-RANKL pathway > mdx mice treated with anti-RANKL, anti-TRAIL, combination of anti-RANKL and anti-TRAIL, truncated OPG-Fc (+ 43%) and full-length OPG-Fc all (greatest effect, + 162%) exhibited significantly increased maximum specific force (EDL) > Full-length OPG-Fc treated mdx mice were able to travel significantly further pre- and post-eccentric exercise, and significantly more (75%) were able to complete the downhill running protocol (PBS-treated mdx mice: 10%) > Full-length OPG-Fc treatment, but not muscle RANK deletion, significantly prevented the loss of force following repetitive eccentric contractions and significantly increased SERCA activity (EDL, over different Ca2+ concentrations: pCa 7.6–4.7) in mdx mice > Full-length OPG-Fc induced a 6-fold significant increase in EDL SERCA-2a protein levels (but not SERCA-1a) in mdx mice, compared to PBS-treated mdx mice > Full-length OPG-Fc treatment rescued maximal ATPase activity in mdx EDL muscles |
*An anti-RANKL treatment reduces muscle inflammation and dysfunction and strengthens bone in dystrophic mice. Hamoudi et al., 2019 [39] | WT and mdx/utrn+/− mice were treated with 1 or 4 mg/kg anti-mouse RANKL (IK22–5) or PBS. Intraperitoneal injections given every 3 days, from 16 to 20 weeks of age | > RANK and RANKL protein levels were higher in mdx/utrn+/− mice compared to WT > IK22-5 treatment significantly improved the specific force and significantly decreased the muscle mass to body weight ratio of mdx EDL and mdx soleus muscles compared with PBS-treated mdx/utrn+/− mice > IK22-5 did not protect mdx EDL and mdx soleus muscles from repeated eccentric contraction-induced force loss > IK22-5 significantly reduced (35%) serum creatine kinase (muscle damage marker), reduced fibrotic and damaged areas and myofiber regeneration (as shown by a reduction in Pax7+ cells and centrally nucleated myofibers) of mdx EDL muscles (compared to PBS treated mdx/utrn+/− mice) > IK22-5 promoted a shift to mid-sized myofibers in mdx/utrn+/− mice |
Testing the efficacy of a human full-length OPG-Fc analog in a severe model of cardiotoxin-induced skeletal muscle injury and repair. Bouredji et al., 2021 [37] | Male WT C57BL/10J mice (10–12 weeks old) subject to cardiotoxin (CTX) induced skeletal muscle injury ± intraperitoneal injection of PBS or hFL-OPG-Fc (1 mg/kg/day) for 3 or 7 days | > hFL-OPG-Fc treatment significantly improved muscle integrity, fiber CSA, repair and regeneration (as shown by increased central nuclei, centrally nucleated myofiber CSA, Pax7+ cells, e-MyHC myofibers, β3 integrin and myogenin) and force of CTX-injured soleus muscles after 7 days |
RANKL Mediates Muscle Atrophy and Dysfunction in a Cigarette Smoke-induced Model of Chronic Obstructive Pulmonary Disease. Xiong et al., 2021 [38] | Female C57BL/6 mice subject to 24-week cigarette smoke (CS) protocol ± anti-mouse RANKL (100–250 μg/mouse IK22-5) or isotype control antibody (2A3), twice a week from week 1 to week 24 | > CS significantly increased RANK and RANKL protein levels in the gastrocnemius muscles > CS mice treated with IK22-5 saw significant improvements in body weight, gastrocnemius and soleus weight and myofiber CSA, grip strength, maximal speed, and running time, compared to CS mice > IK22-5 significantly reduced Atrogin-1, MuRF1, myostatin and inflammatory mediators (NF-κB-p65 ratio, TNF-α and IL-6) in the gastrocnemius muscle of CS mice |
RANKL Blockade Reduces Cachexia and Bone Loss Induced by Non‐Metastatic Ovarian Cancer in Mice. Pin et al., 2022 [34] | 8-week-old female NOD-scid/IL2Rgnull (NSG) immunodeficient mice and C26 tumor-bearing 8-week-old CD2F1 male mice were used for cancer related investigations – these mice were given either IK22-5, zoledronic acid, ES-2 cells or C26 cells stably overexpressing RANKL 8-week-old CD2F1 male mice were used for RANKL over-expression (AAV6‐CMV‐RANKL injected into right gastrocnemius) | > Elevated RANKL (via AAV6‐CMV‐RANKL) induced murine muscle atrophy (reduced muscle mass and CSA), muscle weakness (reduced force) and bone loss > Tumor‐derived RANKL (via C26 cells) exacerbated muscle and bone loss in murine cancer cachexia > Anti-RANKL IK22-5 improved muscle mass and strength, preserved bone mass, and normalized RANKL/OPG expression in the mice bearing ovarian cancer > Zoledronic acid improved muscle mass and strength in murine ovarian cancer |
Delayed denervation-induced muscle atrophy in Opg knockout mice. Zhang et al., 2023 [41] | Assessment of Homozygote Opg −/− and WT mice receiving sciatic nerve transection – right hind limb sciatic nerve was exposed and transected, left was just exposed (sham), for 3, 7 and 14 days | > Satellite cells isolated from Opg −/− mice exhibited reduced proliferation but increased differentiation index and fusion index once differentiated for 48 h > Opg knockout mice exhibited reduced body mass, but displayed similar functional recovery (e.g., stride length) as WT mice after denervation > Opg knockout delayed gastrocnemius muscle atrophy after denervation (3–14 days), as shown by significant increases in gastrocnemius CSA and wet weight > In the Opg−/− sham group, MuRF-1 and Atrogin-1 was upregulated, compared to WT. > Denervation reduced MuRF1 and increased Atrogin-1 (Opg−/− gastrocnemius) > Type I (slow-twitch) fibers increased in Opg −/− mice compared to WT, and Opg knockout delayed type IIB myofiber atrophy following denervation > Tet2 expression increased in denervated Opg −/− mice (gastrocnemius muscle) |
*Anti-RANKL Therapy Prevents Glucocorticoid-Induced Bone Loss and Promotes Muscle Function in a Mouse Model of Duchenne Muscular Dystrophy. Jayash et al., 2023 [45] | Dystrophic skeletal muscle function and bone microstructure were assessed in mdx mice treated with deflazacort (DFZ, 1.2 mg/kg/day) or anti-RANKL (IK22-5, 4 mg/kg/3d), or both for 8 weeks | > IK22-5 and DFZ improved grip force performance in mdx mice, yet no synergistic effect was observed > While IK22-5 showed enhanced ex vivo contractile properties of dystrophic muscles, DFZ did not exhibit the same effect. This improvement in function was correlated with decreased muscle damage, fibrosis, and inflammatory cell count > IK22-5, whether alone or in combination with DFZ, also enhanced the trabecular bone structure in mdx mice |
RANKL signaling drives skeletal muscle into the oxidative profile. Cavalcanti de Araújo et al., 2024 [42] | Male C57BL/6 J (WT) and B6.129S4-Tnfrsf11btm1Eac/J (OPG−/−), and OPG+/− mice were used to explore muscle physiology. Skeletal muscle respiratory rate was investigated in WT mice receiving RANKL (1.8 μg/kg/d) for 28 days | > Compared to WT and OPG+/− mice, OPG−/− mice exhibited reduced body weight and increased succinate dehydrogenase in the gastrocnemius muscle. OPG+/− and OPG−/− mice exhibited reduced gastrocnemius weight/body weight (%) compared to WT > OPG−/− soleus muscles showed higher oxygen consumption in the states of oxidative phosphorylation, non-phosphorylating, and noncoupled or maximal mitochondrial electron transport state > RANKL treatment to WT mice increased the number of mitochondria per μm2, succinate dehydrogenase and muscle force production after a fatigue in the gastrocnemius muscle, and increased oxygen consumption in the states of oxidative phosphorylation and noncoupled mitochondrial electron transport in soleus muscles |
