Prognostic significance of lymphangiogenesis in pharyngolaryngeal carcinoma patients

  • Open Access
  • 01.12.2010
  • Research article
Erschienen in:

Abstract

Background

Lymphatic vessel spread is considered a major route for head and neck squamous cell carcinoma metastasis. Formation of new lymphatic vessels could facilitate the process, raising the malignant potential of these tumours. Recent identification of lymphatic markers allows the study of the lymphangiogenesis phenomenon. We searched for molecular events involved in the lymphangiogenic process that could have prognostic value in laryngeal/pharyngeal carcinoma patients.

Methods

104 paraffin-embedded pharyngeal/laryngeal tumour samples were studied. Immunohistochemical analysis of podoplanin and double immunofluorescence analysis of Ki-67 and D2-40 were performed. Lymph vessel density (inside the tumour mass, at its periphery or considered as a whole) and the presence of tumour emboli inside lymphatics were recorded. The proliferative state of endothelial lymphatic cells was evaluated.

Results

Lymphatic vessels were detected inside the tumour mass (75%) and in the surrounding tissue (80%); some of them in a proliferative state. Tumour emboli were detected in a high proportion of the cases (45%). Lymphatic vessel density was higher in the pharyngeal cases (p = 0.0029), in greater size (p = 0.039), more advanced stage primary tumours (p = 0.006) and in carcinomas of patients with affected nodes (p = 0.019). The presence of tumour emboli and a high global vessel density were indicators of poor prognosis (recorded as death from tumour) in the laryngeal group (p = 0.015 and p = 0.027, respectively), but notably not in the pharyngeal one. Interestingly, high global vessel density showed a negative prognostic value among pathologically staged N0 laryngeal carcinomas (p = 0.03).

Conclusions

The lymphangiogenic process correlated with aggressive tumour features (pN category, tumour size, tumour stage), but might play different roles in tumours arising from different anatomic sites.
Our results suggest that detection of tumour emboli and assessment of global vessel density using the D2-40 antibody, may be useful in the clinical practice, as predictors of reduced survival among pN0 laryngeal carcinoma patients.

Electronic supplementary material

The online version of this article (doi:10.1186/1471-2407-10-416) contains supplementary material, which is available to authorized users.

Competing interests

The authors declare that they have no competing interests.

Authors' contributions

DGC carried out the IHC studies and vessel counting and helped to draft the manuscript. JPR participated in its design and contributed to clinical data collection and results interpretation. AA contributed to the pathological assessment of tissue sections. CSN participated in its design and coordination. MVG conceived the study, coordinated and supervised its progression, carried out vessel counting, performed the statistical analysis and wrote the manuscript. All authors read and approved the final manuscript.

Background

Head and neck squamous cell carcinoma (HNSCC) remains a significant cause of morbidity and mortality, afflicting 500.000 new cases worldwide each year[1]. The single most adverse independent prognostic factor for patients with HNSCC is the involvement of regional lymph nodes, but its accuracy could be improved.
Invasion of cells into the surrounding tissue and the destruction of normal tissue architecture are two hallmarks of malignant tumours. Lymphatic vessels serve as the primary conduit for malignant tumour cell to regional lymph nodes[2]. In recent years, increasing evidence support that lymphangiogenesis is involved in the process of lymphatic spread in HNSCC. However, whether cancer cells can metastasize by expansion and invasion of preexisting peritumoural lymphatics, or by the formation and invasion of new lymphatics within tumours remains an unsolved question due to the difficulty in distinguishing lymphatics from blood vessels[38]. Recently, several lymphatic endothelium markers were identified and the most reliable one among them is podoplanin, which is recognised by the monoclonal D2-40 antibody with a high specificity and sensitivity [911].
Using the D2-40 antibody in this study, the presence and density of lymphatic vessels were determined and quantified in laryngeal/pharyngeal carcinomas, and their potential prognostic values were assessed.

Methods

Patients

Paraffin-embedded tissues from 104 patients with pharyngeal or laryngeal squamous cell carcinoma (Table 1) who underwent resection of their tumours at the Hospital Universitario Central de Asturias (HUCA) (2000 - 2006) were obtained from the Pathology Department. Having a balanced number of cases for every clinicopathologic category was one of the patient inclusion criteria. Prior to the start the study was evaluated for approval according to the institutional review board's guidelines on ethical procedures. None of the patients had received radio/chemotherapy prior to resection or were thought to have distant metastasis at the time of diagnosis. Mean follow-up periods are shown in Table 1. Endpoints examined were nodal involvement, disease specific and overall survival.
Table 1
Clinicopathologic features of the laryngeal/pharyngeal squamous cell carcinoma patients and their primary tumours (N= 104).
Clinicopathologic feature
N° cases (%)
Age
Mean 60 (33-86)
Sex

   Male
98 (94.2)
   Female
6 (5.8)
Tumour site

   Hypopharynx
18 (17.5)
   Oropharynx
31 (30.1)
   Glottis
30 (29.1)
   Supraglottis
24 (23.3)
T category

   1
19 (18.3)
   2
20 (19.2)
   3
30 (28.9)
   4
35 (33.6)
N category

   0
47 (45.2)
   1
8 (7.7)
   2
41 (39.4)
   3
8 (7.7)
Degree of differentiation

   Well
48 (49)
   Moderate
32 (32.6)
   Poor
18 (18.4)
Tumour stage (TNM a )

   I
18 (18.18)
   II
10 (10.10)
   III
14 (14.14)
   IV
57 (57.58)
Status

   Alive without tumour
49 (47)
   Alive with tumour
3 (3)
   Death of tumour
34 (33)
   Death other causes
18 (17)
Recurrence

   No
66 (66)
   Yes
34 (34)
Toxic habits

   Cigarette smoking
103 (99)
   Alcohol consumption
91 (88)
Mean follow up (months) (range)

   Whole population
23 (10 - 67)
   Larynx
26 (9 - 67)
   Pharynx
20 (10 - 66)
aTNM staging system of the International Union Against Cancer - 6th Edition[20].

Immunohistochemical detection of lymphatic vessels

4 μm formalin-fixed paraffin-embedded sections were incubated overnight at 54-56°C, deparaffinized in xylene and rehydrated through decreasing graded ethanol solutions. After endogenous peroxidase activity suppression (3% hydrogen peroxide, 10 min) and antigen retrieval (boiling in 10 mM citrate buffer, pH 6.0), immunostaining was performed with D2-40 mouse monoclonal antibody against human podoplanin (M2A antigen, Covance, California, USA) (1:100 dilution, 4°C, overnight in a humid chamber). Staining was done by using the DakoCytomation Envision Plus peroxidase mouse system. The stained protein was visualized using the DAB solution (Dako), and lightly counterstained with Mayers-haematoxilyn.
To ascertain the specificity of the antibody immunoreactivity, a negative control was carried out by exclusion of the primary antibody. In this case, immunolabeling was completely abolished.

Evaluation of staining

Quantitative analysis of the intratumoural and peritumoural lymphatic vessel density was performed by two independent observers (DGC and MVG) in a blinded fashion. Three fields with the highest lymphatic vascular density were identified (Olympus BX-51 microscope; x100 magnification), and the vessels were counted (×400 magnification) both within the tumour area (intratumoural lymphatic density; ILD) and within an area 500 μm from the tumour border (peritumoural lymphatic density; PLD). Lymphatic vessel density (LVD), regardless of the vessel location with respect to the tumour, was also considered. Lymphatic density was defined as the number of lymphatic vessels per mm2.
We also evaluated invasion of the podoplanin-positive lymphatic vessels by cancer cells. Lymphatic invasion (LI) was considered to be present if at least one tumour cell cluster (a tumour embolus) was clearly visible inside a podoplanin-positive vessel. Cases were classified as LI positive or negative depending on the presence or absence of tumour emboli, respectively.

Immunofluorescence study

Ten representative cases were selected on the basis of the images of the lymphatic vessels obtained in D2-40 IHC. For double immunostaining, deparaffined and rehydrated sections were rinsed in 0.05 M Tris-buffered saline (TBS; pH 7.5) containing 0.1% bovine serum albumin and 0.2% Triton X-100. Endogenous peroxidase activity and non-specific binding were blocked with 3% H202 and 50% fetal calf serum (Sigma), respectively, and the sections were incubated overnight with the primary antibodies in a humid chamber at 4°C: mouse D2-40 (M2A antigen, Covance, California, USA) and rabbit anti-ki67 (Abcam ab833). After the incubation with the primary antibodies, sections were incubated for 1 hr at room temperature with Texas red-labelled sheep anti-rabbit immunoglobulin G (IgG) and fluorescein isothiocyanate-conjugated sheep anti-mouse IgG, both diluted at 1:100 (Amersham). Finally, tissue sections were photographed with a confocal-laser scanning microscope (Bio-Rad MR-600; Servicio de Proceso de Imágenes de la Universidad de Oviedo).

Statistical analysis

For statistical purposes, clinicopathological features were dichotomized as: pT category: 1-2, 3-4; pN category: N0, N1-3; TNM stage: I-II, III-IV. The molecular data distributed among the different clinical groups of tumours were tested for significance employing the χ2 test for categorical variables and t-Student/ANOVA or Mann Whitney/Kruskal-Wallis tests for parametric and non parametric continuous variables, respectively. Survival curves (disease-specific and overall) were calculated using the Kaplan-Meier product limit estimate. Differences between survival times were analyzed by the log-rank method. Multivariate Cox proportional hazards models were used to examine the relative impact of either variables demonstrated to be statistically significant in univariate analysis or those variables likely to have an effect on the outcome. P-values < 0.05 (based on two-tailed statistical analysis) were considered statistically significant. All the statistical analyses were performed with the statistical software SPSS 12.0 (SPSS, Inc., Chicago, IL).

Results

Results are reported following the REMARK guidelines (REporting recommendations for tumor MARKer prognostic studies)[12].

Lymphatic density quantification

Immunohistochemical detection of podoplanin with D2-40 antibody shows strong specific reactivity with lymphatic endothelial cells, while the endothelial cells of blood vessels show no signal (Figure 1A, E).
Figure 1
Immunohistochemical identification of lymphatic vessels. Immunohistochemical identification of lymphatic vessels using D2-40 antibody against podoplanin in an oropharyngeal (A) and a supraglottic tumour (E). Detection of intratumoural lymphatics in an oropharyngeal (B) and a supraglottic tumour (F). Detection of peritumoural lymphatics in a supraglottic tumour. The basal layer of the epithelium and the margin of the tumour mass gave positive signal for podoplanin (C). Detection of peritumoural lymphatics in a glottic tumour that stained positive for podoplanin (G). Example of one representative podoplanin positive tumour cell embolus inside a podoplanin positive lymphatic vessel of an oropharyngeal (D) and a supraglottic carcinoma (H). Scale bar, 250 μm.
Bild vergrößern
D2-40-positive lymphatic vessels could be identified between islands of neoplastic epithelium (Figure 1B, F) and at the tumour periphery (Figure 1C, G). Podoplanin expression was also detected in tumour cells at the tumour border (Figure 1B-C).
The percentages of the cases with positive lymphatic vessel stainings, locations of the positive standings (ILD, PLD or LVD), mean values, and score ranges in the 104 HNSCC, 54 laryngeal and 50 pharyngeal carcinoma samples are summarized in Tables 2, 3 and 4.
Table 2
Correlations between lymphatic vessel density and clinicopathologic features in the HNSCC series (N = 104).
ALL CASES
ILD
PLD
LVD
Lymphatic Invasion
Frequency
75% (78/104)
80% (83/104)
94% (98/104)
42.72% (44/103)
Mean (S.E.)
14.8 (1.33)
22.0 (1.59)
22.3 (1.19)

Score range
0-78.4
0-82.2
0-79.3


N
Mean range
p #
N
Mean (S.E)
p ¥
N
Mean (S.E)
p ¥
Absent
Present
Total
p*
Anatomic site

Pharynx
50
63.34
0.0004
50
27.41 (2.57)
0.0072
50
26.47 (1.92)
0.0029
21
29
50
0.002
Larynx
54
42.46

54
18.47 (2.03)

54
18.98 (1.56)

38
15
53

Total
104

104

104

59
44
103

pT

T1-2
39
39.09
0.0000
39
19.19 (2.47)
0.099
39
19.20 (2.03)
0.039
29
10
39
0.006
T3-4
65
60.55

65
24.91 (2.21)

65
24.61 (1.60)

30
34
64

Total
104

104

104

59
44
103

Nodal involvement

Free
47
42.44
0.0020
47
18.60 (2.37)
0.0230
47
19.34 (1.67)
0.0190
35
12
47
0.001
Affected
57
60.80

57
26.20 (2.27)

57
25.24 (1.82)

24
32
56

Total
104

104

104

59
44
103

Tumour Stage

I-II
28
32.98
0.0001
28
14.67 (2.44)
0.0010
28
16.89 (2.25)
0.0060
24
4
28
0.0000
III-IV
71
56.71

71
25.83 (2.14)

71
24.76 (1.57)

31
38
69

Total
99

99

99

55
42
97

Recurrence

No
66
50.98
0.8167
66
20.29 (2.17)
0.0729
66
21.15 (1.54)
0.1649
38
27
65
0.8050
Yes
34
49.57

34
26.86 (2.78)

34
25.04 (2.47)

19
15
34

Total
100

100

100

57
42
99

ILD, Intratumoural Lymphatic Density; PLD, Peritumoural Lymphatic Density; LVD, Lymphatic Vessel Density
S.E., Standard Error
p# (U Mann-Whitney); p¥ (t Student); p* (chi square)
Frequencies (cases with lymph vessels), mean values and score ranges of ILD, PLD and LVD in the whole series (N=104). Comparison of mean ILD, PLD and LVD values among different categories of clinico-pathological features. Distribution of tumours according to lymphatic invasion (LI) and clinicopathological features.
Table 3
Correlations between lymphatic vessel density and clinicopathologic features in the laryngeal carcinoma series (N = 54).
LARYNX
ILD
PLD
LVD)
Lymphatic Invasion
Frequency
57.41% (31/54)
55.56% (30/54)
87.04% (47/54)
28.30% (15/53)
Mean (S.E.)
10.59 (1.65)
18.47 (2.03)
18.98 (1.56)

Score range
0-41.56
0-60.45
0-44.71


N
Mean range
p#
N
Mean (S.E)
N
Mean (S.E)
Absent
Present
Total
p*
Anatomic site

Glottis
30
23.45
0.028
30
15.22 (2.43)
0.073
30
16.14 (2.06)
0.042
23
6
29
0.176
Supraglottis
24
32.56

24
22.54 (3.30)

24
22.52 (2.24)

15
9
24

Total
54

54

54

38
15
53

pT

T1-2
28
22.05
0.006
28
15.95 (2.85)
0.2
28
15.98 (2.38)
0.044
25
3
28
0.003
T3-4
26
33.37

26
21.19 (2.86)

26
22.20 (1.84)

13
12
25

Total
54

54

54

38
15
53

Nodal involvement

Free
38
25.38
0.112
38
16.63 (2.23)
0.165
38
17.72 (1.81)
0.219
30
8
38
0.062
Affected
16
32.53

16
22.85 (4.27)

16
21.96 (3.03)

8
7
15

Total
54

54

54

38
15
53

Tumour Stage

I-II
24
20.92
0.004
24
13.95 (2.52)
0.045
24
15.05 (2.35)
0.023
20
4
24
0.073
III-IV
30
32.77

30
22.09 (2.92)

30
22.12 (1.94)

17
11
28

Total
54

54

54

37
15
52

Recurrence

No
43
28.35
0.169
43
17.02 (2.28)
0.218
43
18.60 (1.80)
0.685
29
13
42
0.492
Yes
10
21.20

10
23.55 (4.7)

10
20.28 (3.57)

8
2
10

Total
53

53

53

37
15
52

ILD, Intratumoural Lymphatic Density; PLD, Peritumoural Lymphatic Density; LVD, Lymphatic Vessel Density
S.E., Standard Error
p# (U Mann-Whitney); p¥ (t Student); p* (chi square)
Frequencies (cases with lymph vessels), mean values and score ranges of ILD, PLD and LVD in laryngeal carcinoma population (N=54). Comparison of mean ILD, PLD and LVD values among different categories of clinico-pathological features. Distribution of tumours according to lymphatic invasion (LI) and clinicopathological features.
Table 4
Correlations between lymphatic vessel density and clinicopathologic features in the laryngeal carcinoma series (N = 50).
PHARYNX
ILD
PLD
LVD
Lymphatic Invasion
Frequency
90% (45/50)
90% (45/50)
96% (48/50)
58% (29/50)
Mean (S.E.)
19.14 (1.97)
27.41 (2.57)
26.47 (1.92)

Score range
0-78.39
0-82.17
8.5 -79.34


N
Mean (S.E)
N
Mean (S.E)
N
Mean range
p#
Absent
Present
Total
p*
Anatomic site

Hypopharynx
18
19.92 (3.48)
0.8600
18
30.87 (3.91)
0.3470
18
29.67
0.0810
12
6
18
0.0230
Oropharynx
31
19.18 (2.45)

31
25.70 (3.46)

31
22.29

9
22
31

Total
49

49

49

21
28
49

pT

T1-2
11
14.71 (3.53)
0.236
11
27.45 (3.12)
0.993
11
29.18
0.343
4
7
11
0.668
T3-4
39
20.39 (2.30)

39
27.39 (3.11)

39
24.46

17
22
39

Total
50

50

50

21
29
50

Nodal involvement

Free
9
16.30 (3.90)
0.3330
9
26.94 (7.77)
0.3450
9
27.50
0.6550
5
4
9
0.3630
Affected
41
19.77 (2.25)

41
27.51 (2.69)

41
25.06

16
25
41

Total
50

50

50

21
29
50

Tumour Stage

I-II
4
12.12 (7.01)
0.3720
4
19.05 (8.74)
0.3650
4
28.13
0.4280
4
0
4
0.0100
III-IV
41
19.60 (2.29)

41
28.57 (2.99)

41
22.50

14
27
41

Total
45

45

45

18
27
45

Recurrence

No
23
19.19 (2.37)
0.9140
23
26.41 (4.34)
0.7410
23
24.39
0.8480
9
14
23
0.6420
Yes
24
18.73 (3.45)

24
28.24 (3.43)

24
23.63

11
13
24

Total
47

47

47

20
27
47

ILD, Intratumoural Lymphatic Density; PLD, Peritumoural Lymphatic Density; LVD, Lymphatic Vessel Density
S.E., Standard Error
p# (U Mann-Whitney); p¥ (t Student); p* (chi square)
Frequencies (cases with lymph vessels), mean values and score ranges of ILD, PLD and LVD in pharyngeal population (N=50). Comparison of mean ILD, PLD and LVD values among different categories of clinico-pathological features. Distribution of tumours according to lymphatic invasion (LI) and clinicopathological features.

Proliferating lymph vessels

Double immunofluorescence assay was performed with D2-40 and the proliferation marker ki-67 in ten representative cases. Vessels were deemed positive for proliferation when they harboured at least one ki-67 positive cell (Figure 2A-L) and were observed inside the tumour mass or in its periphery.
Figure 2
Proliferation state of lymphatic vessels. Examples of podoplanin positive (green) proliferative (ki-67 positive, red) lymphatic vessels in an oropharyngeal (A-D and I-L) and a supraglottic carcinoma (E-H). D2-40 positive (green) proliferating tumour mass inside a lymphatic vessel of a supraglottic carcinoma (M-P) (lymphatic invasion positive case, ki-67 positive embolus, red). First and second columns D2-40 -green- and ki-67 -red- immunstainings, respectively; third and last columns, DAPI (blue) and merged images. Scale bar, 10 μm.
Bild vergrößern

Lymphatic invasion (LI)

Podoplanin-positive carcinoma cells could be visualized inside lymph vessels (irrespective of vessel location) in 43% of the cases (44/103, LI positive) (Figure 1D, H). Figure 2M-P shows the proliferation state (ki-67) of a D2-40 positive tumour mass inside a lymphatic vessel (LI positive case).

Correlations with clinicopathologic features

Considering the whole series for analysis, higher mean ILD, PLD and LVD values were significantly associated with greater tumour size, lymph node metastasis, advanced tumour stage and pharyngeal tumour site (Table 2). Tables 3 and 4 summarize ILD, PLD and LVD mean values and LI distribution among clinicopathological features in laryngeal and pharyngeal carcinomas, respectively. Of note, while no association was found in the pharyngeal group, LVD correlated with greater tumour size and more advanced tumour stage within the laryngeal population (p < 0.05, each).
The normal glottis is a particularly interesting site, since it is a lymph vessel free region. In our series, 13 out of the 29 glottic cases (45%) showed lymphatics within the tumour mass, 3 of which were T1 tumours.
Importantly, the presence of tumour emboli (lymphatic invasion) correlated with anatomic site (28% in laryngeal tumours vs. 58% in pharyngeal tumours; p = 0.002) and were more frequently observed in tumours of patients with affected lymph nodes (p = 0.001), in greater size tumours (p = 0.006) and in more advanced stage tumours (p = 0.000).

Survival analysis

The five-year disease specific and overall survival rates for the whole population were 52% and 28%, respectively. As expected, tumours arising in the larynx, those with T1-2 category, stage I-II and patients without lymph node involvement, had a better prognosis (p < 0.05).
For the survival analysis, lymphatic vessel variables (ILD, PLD, LVD) were categorized into high vessel density cases vs. the rest, attending to the median value of the lymph vessel density in the positive population (Table 5). In this way, a high LVD (irrespective of vessel location) had a negative impact on disease specific survival (p = 0.045) and on overall survival (p = 0.0564). In addition, disease specific (Figure 3A) and overall survival were worse for patients with tumour emboli within the vessels (LI positive) (p = 0.045 and p = 0.0312, respectively). Importantly, these results were observed for the laryngeal tumours (high LVD (p = 0.027), presence of emboli; p = 0.015) (Figure 3B) but not in the pharyngeal ones.
Table 5
Impact of the lymphatic vessel density on survival.

ALL CASES (N = 104)
Larynx (N = 54)
Pharynx (N = 50)

Median
p
Median
p
Median
p
ILD
13.22
0.15
7.56
0.3262
18.42
0.6831
PLD
22.67
0.3898
20.78
0.6321
26.92
0.7139
LVD
22.04
0.045
20.78
0.027
22.98
0.334
LI

0.045

0.015

0.5933
Kaplan Meier disease specific survival analysis p-values for ILD, PLD, LVD - dichotomized according to their median values - in the whole population, laryngeal and pharyngeal tumours
Figure 3
Lymphatic Vessel Density and survival. Disease specific survival curves for pharyngolaryngeal squamous carcinoma patients (A) or laryngeal carcinoma patients (B) stratified by the presence of tumour emboli inside lymphatics. pN0 HNSCC patients (C) or pN0 laryngeal carcinoma (D) stratified according to LVD (null-low vs. high). The number of patients remaining after every ten/twenty months period is indicated along each curve. Log-rank test significance is indicated.
Bild vergrößern
A very interesting observation could be made for the 47 HNSCC patients with pN0 tumours (38 laryngeal and 9 pharyngeal): 19 cases showing a high LVD (14 laryngeal and 5 pharyngeal) had a poorer prognosis than the rest (p = 0.005) (Figure 3C). Among the group of 38 pN0 laryngeal tumours a high LVD was the only marker of poor prognosis in univariate analysis (p = 0.03) (Figure 3D).
None of these variables reached statistical significance when multivariate Cox analysis was performed.

Discussion

In the present study we investigated the existence of tumour lymphangiogenesis in a cohort of 104 laryngeal/pharyngeal carcinoma patients and evaluated whether ILD, PLD or LVD correlated with the presence of lymph node metastasis; we also addressed the prognostic significance of the above parameters on the disease specific and overall survival of these patients.
As previously described, podoplanin was detected in tumour cells [13] and lymphatic vessels were observed both within the tumour mass (ILD) and in the peritumoural area (PLD)[5, 1417]. Higher ILD correlated with a more aggressive tumour phenotype and high LVD was predictor of poor survival (p = 0.045). However, when laryngeal and pharyngeal tumours were considered separately, these associations were observed only in laryngeal carcinomas (LVD and survival, p = 0.027), suggesting a different contribution of lymphangiogenesis at different anatomic sites. While heterogeneous results can be found in the literature regarding this question,[5, 1417] our data leave evidence of a more relevant role of lymphangiogenesis in the laryngeal carcinoma subgroup. Anatomic characteristics could account for these differences. The pharynx is a lymph vessel rich area so that virtually all tumours arising there might benefit from this circumstance. In our series 96% pharyngeal tumours were LVD positive and 90% ILD positive. Thus, no differences can be expected to be observed regarding lymph vessel density impact on outcome. In contrast, the larynx (specially the glottis) is a lymph vessel poor region and those tumours able to induce lymphangiogenesis (57% ILD positive cases in our series) might show a selective advantage regarding spread and thus a poorer outcome than those that remain vessel free.
In reference to the existence of dividing cells among lymphatic endothelial cells, we found evidence of at least one proliferative endothelial lymphatic cell in some tumour sections, although their proportion was low. These results are in line with previous reports that point to the existence of an active lymphangiogenesis process in HNSCC[5, 15].
The correlation between ILD and nodal involvement supports the role of intratumoural lymph vessels as a possible route for the spread of tumours to local lymph nodes. Interestingly, tumour emboli (LI, lymphatic invasion) were observed within lymphatics in 43% of tumour samples, a higher frequency than previously reported[5, 15, 17, 18]. Importantly, LI correlated with tumour size, nodal involvement, tumour stage and a reduced survival rate.
Lymphatic cell proliferation and tumour emboli formation may be rare events, difficult to detect by examining small sections of archival tissue at a single time point. Despite this, the detection of proliferating lymphatics in carcinoma tissue and of tumour emboli within lymphatics constitutes considerable evidence for the presence of active lymphangiogenesis in this type of malignancy. Additionally, we present evidence of a true lymphangiogenic process in the larynx, since lymphatics were detected in pT1 tumours arising in the glottis, a physiologically lymph vessel free site. This observation would indicate the formation of new vessels in these cases. On the other hand, the presence of lymphatics in the pT2-4 glottic tumours would not necessarily point to this phenomenon, since vessels might also result from their being entrapped as growing tumours reached the vessel rich areas, such as the paraglottic space, supraglottis or subglottis.
Controversial results can be found in the literature regarding the specific contribution of intra and peritumoural lymphatic vessels to tumour spread. Functional studies in animal models have shown that intratumoural lymphatic vessels are compressed and nonfunctional. However, some studies on human tumour samples reveal that intratumoural lymphatics are involved in nodal metastasis and that ILD is a significant indicator of poor prognosis[5, 14, 17]. Other authors describe an association of high PLD with shorter disease-free survival,[16, 19] whereas a correlation between higher PLD and a more favourable outcome has also been reported[17]. These heterogeneous results could arise from the different methods used to quantify LVD and could reflect subjective factors and the intrinsic difficulties found in intra vs. peritumoural vessel identification when studying single tissue sections taken at a single time point, which might yield a misleading vessel classification, limiting the potential value of these variables. Although both ILD and PLD contribute to tumour spread to lymph nodes, from our experience, LVD counting (regardless of their location with respect to the tumour) is more reproducible and might be a more reliable marker of poor prognosis, especially within the laryngeal subgroup.
Remarkably, although nodal involvement had a negative prognostic value, this prediction could be refined among the pN0 laryngeal tumour population, according to their LVD. Thus, significant differences on survival times were found for cases showing a high LVD (poorer outcome). This observation was also made in the whole series of carcinomas but not in the pharyngeal subgroup, and might be a useful tool in the pN0 laryngeal cancer patients' clinical management.

Conclusions

In summary, our results suggest a differential implication of lymphangiogenesis in tumours arising from different anatomical head and neck sites. We propose that LVD assessment and tumour emboli detection using the D2-40 antibody should be considered as potential prognostic tools for laryngeal tumours. This would merit further large-scale validation analyses for the eventual future incorporation of these potential markers into clinical practice.

Acknowledgements

We thank Olivia García Suarez and Marta Sánchez Pitiot for their technical help and Dr Gloria H Su for critical reading of the manuscript. This study was supported by grant from Programa Ramón y Cajal -Ministerio de Educación y Ciencia, Spain (MVG), FICYT (PC 04-20) (CS) and Obra Social CajAstur (DGC). The Instituto Universitario de Oncología is supported by Obra Social Cajastur.
Open Access This article is published under license to BioMed Central Ltd. This is an Open Access article is distributed under the terms of the Creative Commons Attribution License ( https://creativecommons.org/licenses/by/2.0 ), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Competing interests

The authors declare that they have no competing interests.

Authors' contributions

DGC carried out the IHC studies and vessel counting and helped to draft the manuscript. JPR participated in its design and contributed to clinical data collection and results interpretation. AA contributed to the pathological assessment of tissue sections. CSN participated in its design and coordination. MVG conceived the study, coordinated and supervised its progression, carried out vessel counting, performed the statistical analysis and wrote the manuscript. All authors read and approved the final manuscript.
Download
Titel
Prognostic significance of lymphangiogenesis in pharyngolaryngeal carcinoma patients
Verfasst von
Darío Garcia-Carracedo
Juan Pablo Rodrigo
Aurora Astudillo
Carlos Suarez Nieto
Maria Victoria Gonzalez
Publikationsdatum
01.12.2010
Verlag
BioMed Central
Erschienen in
BMC Cancer / Ausgabe 1/2010
Elektronische ISSN: 1471-2407
DOI
https://doi.org/10.1186/1471-2407-10-416

Authors’ original submitted files for images

1.
Zurück zum Zitat Stewart B, Kleihues P: World Cancer Report. 2003, Geneva: International Agency for Research on Cancer
2.
Zurück zum Zitat Wicki A, Christofori G: The potential role of podoplanin in tumour invasion. British journal of cancer. 2007, 96 (1): 1-5. 10.1038/sj.bjc.6603518.CrossRefPubMed
3.
Zurück zum Zitat Clarijs R, Ruiter DJ, de Waal RM: Lymphangiogenesis in malignant tumours: Does it occur?. The Journal of pathology. 2001, 193 (2): 143-146. 10.1002/path.808.CrossRefPubMed
4.
Zurück zum Zitat Williams CS, Leek RD, Robson AM, Banerji S, Prevo R, Harris AL, Jackson DG: Absence of lymphangiogenesis and intratumoural lymph vessels in human metastatic breast cancer. The Journal of pathology. 2003, 200 (2): 195-206. 10.1002/path.1343.CrossRefPubMed
5.
Zurück zum Zitat Beasley NJ, Prevo R, Banerji S, Leek RD, Moore J, van Trappen P, Cox G, Harris AL, Jackson DG: Intratumoral lymphangiogenesis and lymph node metastasis in head and neck cancer. Cancer research. 2002, 62 (5): 1315-1320.PubMed
6.
Zurück zum Zitat Pepper MS: Lymphangiogenesis and tumor metastasis: myth or reality?. Clin Cancer Res. 2001, 7 (3): 462-468.PubMed
7.
Zurück zum Zitat Leu AJ, Berk DA, Lymboussaki A, Alitalo K, Jain RK: Absence of functional lymphatics within a murine sarcoma: a molecular and functional evaluation. Cancer research. 2000, 60 (16): 4324-4327.PubMed
8.
Zurück zum Zitat Stacker SA, Caesar C, Baldwin ME, Thornton GE, Williams RA, Prevo R, Jackson DG, Nishikawa S, Kubo H, Achen MG: VEGF-D promotes the metastatic spread of tumor cells via the lymphatics. Nature medicine. 2001, 7 (2): 186-191. 10.1038/84635.CrossRefPubMed
9.
Zurück zum Zitat Evangelou E, Kyzas PA, Trikalinos TA: Comparison of the diagnostic accuracy of lymphatic endothelium markers: Bayesian approach. Mod Pathol. 2005, 18 (11): 1490-1497. 10.1038/modpathol.3800457.CrossRefPubMed
10.
Zurück zum Zitat Van der Auwera I, Cao Y, Tille JC, Pepper MS, Jackson DG, Fox SB, Harris AL, Dirix LY, Vermeulen PB: First international consensus on the methodology of lymphangiogenesis quantification in solid human tumours. British journal of cancer. 2006, 95 (12): 1611-1625. 10.1038/sj.bjc.6603445.CrossRefPubMedPubMedCentral
11.
Zurück zum Zitat Kahn HJ, Marks A: A new monoclonal antibody, D2-40. for detection of lymphatic invasion in primary tumors. Laboratory investigation; a journal of technical methods and pathology. 2002, 82 (9): 1255-1257.CrossRefPubMed
12.
Zurück zum Zitat McShane LM, Altman DG, Sauerbrei W, Taube SE, Gion M, Clark GM: Reporting recommendations for tumor marker prognostic studies (REMARK). Journal of the National Cancer Institute. 2005, 97 (16): 1180-1184. 10.1093/jnci/dji237.CrossRefPubMed
13.
Zurück zum Zitat Yuan P, Temam S, El-Naggar A, Zhou X, Liu DD, Lee JJ, Mao L: Overexpression of podoplanin in oral cancer and its association with poor clinical outcome. Cancer. 2006, 107 (3): 563-569. 10.1002/cncr.22061.CrossRefPubMed
14.
Zurück zum Zitat Audet N, Beasley NJ, MacMillan C, Jackson DG, Gullane PJ, Kamel-Reid S: Lymphatic vessel density, nodal metastases, and prognosis in patients with head and neck cancer. Archives of otolaryngology--head & neck surgery. 2005, 131 (12): 1065-1070.CrossRef
15.
Zurück zum Zitat Kyzas PA, Geleff S, Batistatou A, Agnantis NJ, Stefanou D: Evidence for lymphangiogenesis and its prognostic implications in head and neck squamous cell carcinoma. The Journal of pathology. 2005, 206 (2): 170-177. 10.1002/path.1776.CrossRefPubMed
16.
Zurück zum Zitat Franchi A, Gallo O, Massi D, Baroni G, Santucci M: Tumor lymphangiogenesis in head and neck squamous cell carcinoma: a morphometric study with clinical correlations. Cancer. 2004, 101 (5): 973-978. 10.1002/cncr.20454.CrossRefPubMed
17.
Zurück zum Zitat Maula SM, Luukkaa M, Grenman R, Jackson D, Jalkanen S, Ristamaki R: Intratumoral lymphatics are essential for the metastatic spread and prognosis in squamous cell carcinomas of the head and neck region. Cancer research. 2003, 63 (8): 1920-1926.PubMed
18.
Zurück zum Zitat Kyzas PA, Stefanou D, Batistatou A, Agnantis NJ, Nakanishi Y, Hirohashi S, Charalabopoulos K: Dysadherin expression in head and neck squamous cell carcinoma: association with lymphangiogenesis and prognostic significance. The American journal of surgical pathology. 2006, 30 (2): 185-193. 10.1097/01.pas.0000178090.54147.f8.CrossRefPubMed
19.
Zurück zum Zitat Longatto Filho A, Oliveira TG, Pinheiro C, de Carvalho MB, Curioni OA, Mercante AM, Schmitt FC, Gattas GJ: How useful is the assessment of lymphatic vascular density in oral carcinoma prognosis?. World J Surg Oncol. 2007, 5: 140-10.1186/1477-7819-5-140.CrossRefPubMedPubMedCentral
20.
Zurück zum Zitat Sobin LH, Wittekind C: TNM classification of malignant tumors. 2002, New York: Wiley-Liss, 6
Zurück zum Zitat The pre-publication history for this paper can be accessed here:http://www.biomedcentral.com/1471-2407/10/416/prepub

Neu im Fachgebiet Onkologie

HRT nach Oophorektomie auch bei BRCA-Varianten sicher?

Eine Hormonersatztherapie (HRT) nach einer risikoreduzierenden bilateralen Salpingo-Oophorektomie geht bei pathogenen BRCA-Varianten nicht mit einem erhöhten Brustkrebsrisiko einher. Allerdings sind die statistischen Unsicherheiten der Studie sehr groß.

Künstliche intelligente Melanomdiagnostik – „Niveau von Dermatologen erreicht“

Verfahren der artifiziellen Intelligenz für die Mustererkennung wecken auch in der Dermatologie hohe Erwartungen. Dass sich die künstlichen im Vergleich zu menschlichen Dermatologen in der Melanomdiagnostik achtbar schlagen, hat eine Metaanalyse gezeigt.

Typ 2 Diabetes verschlechtert Prognose von Männern mit frühem Melanom

Bei Patientinnen und Patienten mit Melanom und gleichzeitigem Typ-2-Diabetes zeigen sich deutliche Unterschiede im Krankheitsverlauf zwischen den Geschlechtern. Eine dänische Registeranalyse untersuchte erstmals geschlechts- und stadiumsspezifische Risiken für Rezidiv und Mortalität.

NMIBC: Wie häufig sind Rückfälle nach fünfjähriger Rezidivfreiheit?

Eine dänische Registerstudie analysierte über einen Zeitraum von 14 Jahren das Risiko für Rezidive und Progressionen bei nicht muskelinvasiven Harnblasenkarzinomen (NMIBC) sowie das Langzeitrisiko nach einer fünfjährigen rezidivfreien Phase. Die Ergebnisse liefern wichtige Anhaltspunkte für die Optimierung von Nachsorgestrategien.

Update Onkologie

Bestellen Sie unseren Fach-Newsletter und bleiben Sie gut informiert.

Bildnachweise
Ältere Dame hält Tabletten und Packungsbeilage in den Händen/© Vladimir Vladimirov / Getty Images / iStock (Symbolbild mit Fotomodell)
