Role of IAPs in prostate cancer progression: immunohistochemical study in normal and pathological (benign hyperplastic, prostatic intraepithelial neoplasia and cancer) human prostate

Prostate cancers are generally slow-growing malignancies that are characterized by an imbalance in the rates of cell division and cell death [1]. Classical apoptosis is caused by the activation of caspases, a family of intracellular cysteine proteases that lie in a latent state in cells but become activated in response to a wide variety of cell death stimuli [2]. At the present, inhibitor of apoptosis proteins (IAPs) inhibits at least two of the major pathways for initiation of caspase activation: the mitochondrial pathway with cytochrome c; and the death receptor pathway with the tumour necrosis factor (TNF) family of death receptors [3, 4]. TNF transduction pathway has been described by our group in previous manuscript [5, 6].

IAPs is a gene family that plays an essential role in the negative regulation of apoptosis. IAPs family comprises eight proteins: Survivin, XIAP (ILP-1), c-IAP-1, c-IAP-2, NAIP, ILP-2, apollon (BRUCE) and ML-IAP (LIVIN).

c-IAP-1 and c-IAP-2 proteins are broadly expressed in normal human tissues with a cytoplasmic diffuse location pattern. Expression of c-IAP-1 and c-IAP-2 has been reported in several tumours such as in oesophageal [7], colon [8], uterine cervix [9] or prostate [10]. Several authors suggest that the expression of these proteins is associated with biological characteristic of cancer such as apoptosis [7] or aged-related [8].

The coding sequence of ILP-2 (IAP-like protein 2) [11] is very similar to that of XIAP (ILP-1), with 80% identity at the amino acid level [12]. Northern blot and RT-PCR analysis of both embryonic and adult human tissues reveals that ILP-2 expression is restricted to testis [13]. Overexpression of ILP-2 had no protective effect on death induced by bax or caspase 9 [11, 12].

In human adult tissues, NAIP (neuronal apoptosis-inhibitory protein) transcripts were detected using Northern blot analysis in placenta, liver [14, 15], spleen, lung [15], ovary or testis [16], with minimal expression in a number of other tissues, including foetal tissues [15]. By immunohistochemical analysis Maier et al. [16] described that the presence of NAIP in liver, lung and spleen is most likely due to macrophage infiltration. Choie et al. [17] described overexpression of NAIP in breast cancer patients with unfavourable clinical features, suggesting that NAIP would play a role in the disease manifestation. However, little is known about the clinical relevance of NAIP expression in breast cancer and in our knowledge no report described the presence in human prostate tissue.

Survivin is ubiquitously expressed in embryonic tissues where apoptosis occurs, but is not expressed or expressed at undetectable levels in several adult normal tissues. Overexpresion of survivin has been reported in several tumours such as in breast [16], colon [17], bladder [18], uterus [19], ovary [20], liver [21] or prostate [10, 22]. Moreover, survivin has been reported to be expressed in some preneoplastic and/or benign lesions such as polyps of the colon, breast adenomas and PIN [10].

XIAP has been identified as one of the most potent inhibitor of caspases and apoptosis [23]. XIAP overexpression in tumour cells has been shown to cause an inhibitory effect on cell death besides to induce resistance to chemotherapy [23, 24]. Equally to survivin, XIAP is overexpressed in precancerous PIN lesions [10].

Prostate diseases are chronic diseases that need a long development period. The evolution of PC needs a long period, probably due to the development of early and later precancerous modifications and then to the development of a clinical PC [25]. In this way, several clinical studies suggest that prostatic intraepithelial neoplasia (PIN) precedes carcinoma by 10 years or more, with low-grade PIN first emerging in men in the third decade of life [26, 27].

Prostates were obtained from: (a) transurethral resections from 33 men (aged from 53 to 88 years) with clinical and histopathological diagnosis of BPH; (b) radical prostatectomies from 27 men (aged from 20 to 59 years) diagnosis of low-grade PIN (12 men) or high-grade PIN (15 men); (c) radical prostatectomies from 95 men (aged from 54 to 69 years) with PC of low (Gleason scores < 6, 23 men), medium (Gleason scores 7, 51 men) and high (Gleason scores 8-10, 21 men) Gleason grades, with and without metastasis or lymph node infiltration at the time of surgery; and (d) histologically normal prostates (NP) obtained at autopsy (8-10 hours after death) from 20 men (aged from 20 to 38 years) without histories of reproductive, endocrine or related diseases. Each diagnosed sample was divided into two portions; one portion was immediately processed for immunohistochemistry, while the other portion that was frozen in liquid nitrogen and maintained at -80°C for Western Blotting analysis. In this later portion, cryostat sections were stained with toluidine blue to confirm histopathological diagnosis. Since PIN replace synonymous terms including intraductal dysplasia, marked atypia, hyperplasia with malignant changes or large acinal atypical hyperplasia, the reproductibility of the diagnosis of Low grade PIN is lack. All pathological, clinical or personal data were anonymized and separated from any personal identifiers. This study was made with the consent of the patients' relatives or their family in autopsy cases. All the procedures followed were examined and approved by the Principe de Asturias Hospital Ethics Committee (reference number SAF2007-61928) and were in accordance with the ethical standards of the Committee for Human Experimentation, with the Helsinki Declaration of 1975 (revised in 1983) and the Committee on Publication Ethics (COPE) guidelines.

The primary antibodies used were: rabbit polyclonal antibody XIAP and c-IAP-2; mouse monoclonal antibody survivin; goat polyclonal antibodies ILP-2, c-IAP-1/2 and NAIP (Santa Cruz Biotechnology, Ca, USA). For Western blot analysis [28, 29] antibodies were diluted at 1:250 (survivin, NAIP, c-IAP-2, ILP), 1/500 (c-IAP-1/2, XIAP) and 1:10.000 chicken anti α-actin in TBS with 5% bovine serum albumin (BSA). For immunohistochemistry analysis [30, 31] antibodies were diluted at 1:75 (survivin, c-IAP-2, ILP), 1:100 (NAIP), 1/150 (c-IAP-1/2, XIAP) in TBS.

Immunochemical procedure specificity was checked using negative and positive controls. For negative controls, tissues of each type (normal, BPH and PC) were incubated with blocking peptides (Sta. Cruz Biotechnology) or preimmune serum at the same immunoglobulin concentration used for each antibody. As positive controls, homogenates (for Western Blot) and histologic sections (for immunohistochemistry) of human skin, thymus or tonsils were incubated with the same antibodies.

A comparative histologic quantification of immunolabeling among the different types of prostates was performed for each antibody. From each prostate, six histologic sections were selected at random. In each section, the staining intensity (optic density) per unit surface area was measured with an automatic image analyzer (Motic Images Advanced version 3.2, Motic China Group Co., China) in 5 light microscopic fields per section, using the X20 objective. Delimitation of surface areas was carried out manually using the mouse of the image analyzer. For each positively immunostained section, one negative control section (the following in a series of consecutive sections) was also used, and the optic density of this control section was subtracted from that of the stained section.

From the average values obtained (by the automatic image analyzer) for each prostate, the means ± SD for each prostate type (NP, BPH, PIN and PC) were calculated. The results were corroborated by two different observers. The number of sections examined was determined by successive approaches to obtain the minimum number required to reach the lowest SD. The statistical significance between means of the different prostate group samples was assessed by the one way ANOVA test at p ≤ 0.05, by multiple pairwise comparisons (GraphPad PRISMA 3.0 computer program).

To determine whether the source of material (surgery or autopsy) could be responsible for changes in the immunohistochemical pattern, five prostatic biopsies (taken because of the suspicion of prostatic disease and their histologic study revealed a normal pattern) were processed for immunohistochemistry. The results of the quantitative immunohistochemical study in these biopsies were compared with those of autopsy prostates.

The processes of both cell survival and cell death have involved highly regulated signalling pathways that are currently the subject of intense investigation. The rates of epithelial cell growth and death in adult normal prostate glands are in equilibrium [1]. The signalling pathways that lead to apoptosis or cell growth are beginning to be defined, and a number of proteins have been identified.

We used immunohistochemical analysis in order to know the percentage of positive patients, the location and the expression of each protein studied. So, the immunohistochemical analysis data are used to obtain the optical density data as we described in methods sections.

In normal prostate, we observed immunoexpressions to c-IAP-1/2, c-IAP-2, ILP-2, XIAP and NF-kB (p-50) in the cytoplasm of epithelial cells; p-Elk-1 and p-ATF-2 in the epithelial cell nuclei; but no immunoreaction to NAIP, survivin and NF-kB (p-65) were found (see Table 3). Several publications described survivin expression in normal tissues [26]. However, other authors have been reported that immunoexpression is not detected by immunohistochemistry in normal tissues [27] and has been only described by RT-PCR [25]. Vischioni et al. [28] also described cytoplasmic localization to c-IAP-1/2, c-IAP-2 and XIAP in normal prostate. The cytoplasmic localization described might be related to their binding to plasma membrane receptors such as the bone morphogenic protein type I receptors in the case of XIAP [32] or the tumour necrosis factor-receptor complexes in the case of c-IAP-1 and c-IAP-2. In low grade PIN we obtained similar results to those described in normal prostates samples. These observations could be suggest that expressions of these IAPs in normal prostate and PIN could be promoted the equilibrium between proliferation and apoptosis described in normal tissues. Since these IAPs were found in considerably amounts in BPH, high grade PIN and PC specimens, evaluation of these products can be helpful to discriminate between prostatic tissues that are normal and those subjected to pathologic proliferative processes.

In BPH, we detected immunoreactions to c-IAP-1/2, c-IAP-2, ILP-2, NAIP, survivin, XIAP, p-Elk-1, p-ATF-2 and NF-kB (p50 and p65). Similar results have been described by other authors to survivin [33]. These IAPs that are increased in BPH perhaps might be provoked the lower apoptosis index described in this benign pathology. This agrees with the high levels of other factor relate with proliferation or anti-apoptotic factors (such as NF-kB, bcl-2, mcl-1, p21 or Rb) and reported in the same patients used in this study [4, 30, 34]. De Miguel et al. [35] in the same samples used in this study, described that the proliferation index (measured by Ki-27 nuclear antigen) increased respect to that of the normal prostate, but the apoptotic index (measured by TUNEL) was similar than normal and, therefore, the equilibrium is displaced toward proliferation. These data could be suggests that an active stimulation of cell proliferation and survival occurs.

In PC, we described that the percentage of patients positives to all the IAPs family members studied is similar (c-IAP1/2, NAIP or XIAP), major (ILP-2, Survivin) or minor (c-IAP-2) than in BPH. NF-kB (p50 and p65) changes the location from the cytoplasm to the nucleus [5] whereas p-Elk-1 and p-ATF-2 changes the location from the nucleus to the cytoplasm in most of the PC patients examined [31]. The nuclear translocation of NF-kB activates target genes involved in carcinogenesis, such as IAPs [5]. Cytoplasm location to p-Elk-1 and p-ATF-2 could be mutant form that present altered functions and may be associated with the prostate cancer development [31]. In the other hand, optical density is more elevated in PC than in BPH (c-IAP-2, ILP, NAIP, Survivin, XIAP, NF-kB, p-Elk-1 and p-ATF-2); but only survivin and NF-kB increased with Gleason grade. We observed that immunoreactions were cytoplasmic (c-IAP-1/2, c-IAP-2, ILP, NAIP and survivin) or perinuclear (XIAP). The percentages of patients as well as the optical densities observed in high grade PIN have been similar to those observed in PC. These data also have been obtained by others authors. Similar localization to c-IAP-1, c-IAP-2 and XIAP in PC3 cells was described by McEleny et al. [36] in in vitro studies, suggesting that IAP may be an important contribution to apoptotic resistance in patients with prostate cancer. Krajewska et al. [10] by immunohistochemical analysis of prostate tumour tissues reveals cancer-specific elevations in the expression of cIAP1, cIAP2, survivin and XIAP; but immunostaining data did not correlate with Gleason scores or PSA. Vischioni et al. [28], also described cytoplasmic localization to XIAP. In several prostate cancer cell lines (PC3 and LNCaP), the expression of XIAP was perinuclear [36]. XIAP overexpression in tumour cells has been shown to cause an inhibitory effect on cell death induced by a variety of apoptotic stimuli [23]. In prostate adenocarcinoma, survivin has been shown to be overexpressed in an elevated proportion of patients. Nevertheless, results about correlations among survivin expression and both clinical and pathological features are contradictory [10, 36‐40]. An important finding is the involvement of survivin with resistance to antiandrogen therapy for prostate cancer [39]. At the present and in our knowledge, this is the first manuscript that describes ILP-2 and NAIP in human prostate in vivo tissue. In breast cancer survivin and NAIP overexpression has been associated in unfavourable clinical features [17]. In our data survivin (but not NAIP) only was increased in high Gleason grade. At the same time, we observed different localization to NAIP in cancer (compared to BPH) since not all epithelial cells were positives.

In general, IAPs have been shown to protect cells from a wide range of apoptotic triggers including Fas ligation, bax, activated caspases, cytochrome C, TNFα, some chemotherapeutic agents viral infection and radiation [36]. Elevations in the expression of several IAPs occur as a frequent and early event in the etiology of prostate cancer. Activation of NF-kB (translocation to the nucleus) promotes cell growth and proliferation in prostate cancer cells by regulating the expression of c-myc, cyclin D1 or IL-6 [29, 40]; but also by the up-regulation of the expression of several anti-apoptotic proteins, including the inhibitor of apoptosis proteins (IAPs) [29]. Recent report [41, 42] described IAPs family as downstream targets of activated NF-kB. In previous reports made in the same samples used here we described that in PC, the indexes of proliferation (by Ki-67 nuclear antigen and PCNA) and apoptosis (by TUNEL) were higher than in NP and BPH samples [35]. Nuñez et al. [5] using the same PC samples that we use in this study, also was observed increased levels of NF-kB, concluded that NF-kB is a new predictive marker of prostate cancer. At the same time activation to NF-kB together activation of other transcription factors, also studied in this patients by our group, such ATF-2 and Elk-1 [31] (related with enhanced cell proliferation and survival) might be due the overexpression of several components of the IL-1/NIK/NF-kB or TNF/NF-kB (NIK or p38) pathways [5]. At the same time activation of ATF-2, Elk-1 and NF-kB also are the consequence of p38 pathway (IL-1/p38 or TNF-p38) activation [31].

In summary, it is reasonable to speculate that IAPs could be involved in prostate disorder (BPH, PIN and PC) development since might be provoke inhibition of apoptosis. So, the attempt of these proteins to respond against proliferation is insufficient. At the same time, different transduction pathway such as IL-1/NIK/NF-kB or TNF/NF-kB (NIK or p38) also promotes proliferation by activation of several transcription factors as NF-kB but also Elk-1 or ATF-2. Interpretation of these data suggests that, in prostate cancer, there are a higher number of factors relate with activation of mitogenic signaling cascades. In order to search a dominant target for therapy, it should be taken into account that PC is a heterogeneous disease in which multiple transduction pathways may interact in the uncontrolled apoptosis/cell proliferation. Inhibitions of IAPs, IL-1α and TNFα might be a possible target for PC treatment since IAPs are the proteins that inhibited apoptosis (favour proliferation) and IL-1α and TNFα would affect all the transduction pathway involucrate in the activation of transcription factors related to survival or proliferation (NF-kB, Elk-1 or ATF-2).
