Background
The radiation-induced bystander effect is the appearance of a biological response in nonirradiated cells neighbouring irradiated cells [
1]. The response has been demonstrated in cultured cells and tissues by using different irradiation approaches including low fluences of α-particles [
2,
3], γ-rays [
4,
5], heavy ions [
6,
7], and targeted microbeams which allow cells to be individually irradiated through either the nucleus or cytoplasm [
8‐
10]. Many endpoints have been reported for the bystander responses, including DNA damage markers [
11,
12] cell death [
13], increases in sister chromatid exchanges [
14,
15], micronuclei [
11,
16,
17], mutations [
18,
19] genomic instability [
20,
21], malignant transformation [
22,
23] and gene expression [
24].
Recently, we have found that irradiation through the cytoplasm of a cell has a similar probability of triggering a bystander response to that when the nucleus is directly irradiated [
10,
25]. However, the mechanisms underpinning the bystander effect are still unclear, although cell-to-cell communication [
26‐
28] and several signaling factors such as cytokines [
29], reactive oxygen species (ROS) [
30,
31] and nitric oxide (NO) [
32,
33] have been identified as playing roles. These findings may be of particular importance for exposures at environmentally relevant low doses where cells at risk are traversed by only single tracks of radiation at any one time [
34]. Bystander responses may also be relevant to the therapeutic use of radiation because a mechanistic understanding of the effects may lead to approaches to enhance bystander responses in tumours and also possibly to protect surrounding normal tissues.
Although evidence shows that bystander responses can be induced in many types of cells, it is not known whether there is a radiation-induced bystander effect in breast cancer cells, where the radiosensitivity may be dependent on the role of the cellular estrogen receptor (ER)[
35]. Estrogens and anti-estrogens are important components of breast cancer development and treatment. The experimental data are contradictory as to whether estrogens and anti-estrogens alter the radiation response of breast cancer cells. It has been reported that 17β-estradiol (E2) prevents radiation-induced apoptosis of ER-positive MCF-7 breast cancer cells, probably mediated through the plasma membrane ER [
36]. However, a number of studies have indicated that estradiol treatment increases the radiosensitivity of MCF-7 cells [
37‐
39]. Conversely, treatment with the anti-estrogen, tamoxifen reduces or does not alter the radiosensitivity of MCF-7 cells [
37,
40], although it has no effect on radiosensitivity of ER-negative MDA-MB-231 breast cancer cells [
41]. However, none of these studies have considered the response of breast cells and their modulation by estradiols and anti-estradiols after low dose radiation exposure.
In the present work, we used a charged particle microbeam to deliver exact numbers of helium ions through the nuclei of restricted numbers of MCF-7 and MDA-MB-231 breast cancer cells. We found that radiation-induced bystander responses were generated in both cell lines and that treatment with E2 and/or tamoxifen influenced the bystander response through a ROS-mediated pathway in only MCF-7 cells but not in MDA-MB-231 cells.
Methods
Cell culture and treatments
ER-positive MCF-7 and ER-negative MDA-MB-231 breast cancer cells (obtained from Cancer Research UK) were cultured in DMEM medium supplemented with 10% (v/v) foetal calf serum (FCS), 2 mM L-glutamine, 100 units/ml penicillin, and 100 μg/ml of streptomycin. Cells were grown in a humidified atmosphere with 5% CO
2 in air at 37°C. One day prior to microbeam irradiation, plateau phase cells were seeded at a low density in a φ5 mm central area of the specially designed microbeam dish consisting of a 3 μm thick Mylar film base [
42]. The region prepared for cell seeding had been pre-treated with 1.7 μg/cm
2 Cell-Tak adhesive (Collaborative Biomedical Products, Bedford, MA, USA). One hour after cell seeding, 2 ml of medium was added into the microbeam dish. In some experiments, cells were treated 24 h before and after microbeam irradiation with 10 nM 17-β estradiol (E2), 50 nM tamoxifen (TAM), 150 U/ml of the antioxidants superoxide dismutase (SOD) and catalase (CAT), or the combination of E2 with either TAM or antioxidants (all from Sigma, Poole, Dorset, UK). The concentration of E2 utilized for this study was within the range of physiological concentrations which could saturate the ER. TAM with a concentration of 5-fold excess was used to displace E2 from its receptor. These concentrations were also widely applied in other studies [
37,
43].
Microbeam irradiation
The Gray Cancer Institute microbeam system was used for this study and details of the experimental set-up have been described elsewhere [
42,
44]. To enable individual nuclei to be identified by the microbeam imaging system, the fully-attached cells were stained with 0.2 μg/ml Hoechst 33342 for 1 hr prior to irradiation. Excess stain was removed by washing the cells with serum free medium containing 10 mM HEPES before irradiation, and cells were maintained in this medium during microbeam irradiation. Typically, 1200 ± 50 (mean ± SE) individual cells in total were scanned in the microbeam dish just before irradiation. A fraction of cells, from 1% to 100% of the cells in the population, were individually irradiated through the center of the nucleus with a precise number of helium-3 ions (
3He
2+) with an LET of 100 keV/μm. Using these ions, 99% of cell nuclei could be precisely targeted with an accuracy of ± 2 μm. Immediately after irradiation, the culture medium was replaced with 2 ml of complete medium with or without drugs and incubation continued until treatment for micronucleus analysis.
Micronucleus assay
The cytokinesis block technique was used to assay for micronuclei (MN)
in situ. 24 h after irradiation, the culture medium in the microbeam dishes was replaced with medium containing 1 μg/ml cytochalasin-B. The cells were incubated for a further 48 h then fixed with methanol: acetic acid (9:1 (v/v)) for 20 min. After air-drying, cells were stained with 10 μg/ml acridine orange plus 10 μg/ml Hoechst 33342 for 5 min. This Hoechst treatment enhanced visualisation of both nucleus and micronucleus. MN were scored in binucleated (BN) cells and classified according to the criteria of [
45]. The MN yield, Y
MN, was calculated as the ratio of the number of MN to the number of scored BN cells.
ROS assay
To investigate the possible role of ROS in the E2-induced effect, 2 × 105MCF-7 or MDA-MB-231 cells were treated with 10 nM E2 or E2 plus 150 U/ml SOD and CAT for 24 h. Then, the intracellular ROS level in the cells was measured in situ by using 5',6'-chloromethyl-2',7'-dichlorodi-hydro-fluorescein diacetate (CM-H2DCFDA, Molecular Probes Inc.). Briefly, cells were treated with 3.5 μM CM-H2DCFDA for 20 min at 37°C and then washed with FCS free medium for 15 min. The fluorescence images of at least 100 randomly selected cells per dish were captured using a 3 CCD cooled colour camera (Photonic Science Ltd, East Sussex, UK) attached to a fluorescence microscope (Zeiss Axioskop). The exposure conditions were standardised to allow quantitative comparisons of the relative fluorescence intensity of the cells between groups.
Statistical analysis
Statistical analysis was done on the means of the data obtained from at least three independent experiments. Two replicates were counted for each experimental point in each experiment to determine the micronucleus yield. All results are presented as means ± SE. Significance was assessed using the Student's t-test at P < 0.05.
Discussion
This study finds that, when a fraction of cells are precisely irradiated with a counted number of
3He
2+ particles, the bystander response, measured as an increased yield of MN, can be produced in both non-irradiated MCF-7 and MDA-MB-231 cells, independent of ER status. Radiation-induced signalling factors could contribute to these bystander responses. For example, it has been reported that the conditioned medium from irradiated MCF-7 or MDA-MB-231 cells contained twofold more TGF-β1 than that from nonirradiated cells [
47]. Also significant evidence for the role of paracrine signalling in response to radiation exposure has been reported (See [
48]for a review). Our previous studies have shown that TGF-β1 is an important t bystander signaling factor which can further raise the level of intracellular ROS and NO and then cause DNA damage [
49,
50].
Interestingly, the contribution of the bystander response to cellular damage in ER-positive MCF-7 cells was higher than that in ER-negative MDA-MB-231 cells. Moreover, treatment of cells with E2 increases the radiation-induced bystander damage in the ER-positive MCF-7 cells but not in the ER-negative MDA-MB-231 cells, and this E2-enhanced bystander response in MCF-7 cells can be reversed by tamoxifen, an anti-estrogen reagent.
The effects of E2 on breast cancer cells are complicated and sometimes inconsistent. It has been reported that E2 acts as both a growth factor and a survival factor for breast cancer cells and prevents cell death from apoptosis [
36]. However, E2 is a carcinogen and can induce multiple forms of DNA damage such as single strand breaks, chromosome aberrations, and gene mutations [
51]. We find here that the effect of E2 on DNA damage is dependent on the ER status of the cells. E2 can induce MN in ER-positive MCF-7 cells but not in ER-negative MDA-MB-231 cells, which is in agreement with other studies [
46,
52]. Fisher
et al. suggested that the E2-induced formation of MN was not due to the chromosome damaging activity of estradiol but to stimulation of MCF-7 proliferation. For our experiment, the cells were seeded on dishes pre-treated with Cell-Tak so that the cell plating efficiency was ~100%; shortly after irradiation, the cell growth was blocked by cytochalasin-B. Under these conditions, we did not find that the cell proliferation was increased by E2. Thus, E2-induced MN in MCF-7 cells reported here could not result from increased cell proliferation but is generated from the cytotoxic effect of E2.
Direct evidence in the present study shows that E2-induced responses of ROS and MN induction are ER-dependent. Also, the ROS produced contribute to E2-induced DNA damage in MCF-7 cells since this damage was reduced by antioxidants. It has been reported that several types of free radical-mediated DNA damage can be induced by estrogens and their metabolites. For instance, 8-hydroxyguanine, formed by hydroxyl radical reaction with guanine bases, is increased over control values in DNA of cells incubated with estradiol [
53]. In fact, the genotoxic activity of E2 is thought to be tightly linked to an oxidative element probably involving an ER-mediated mechanism. At physiological concentrations of E2, an ER-mediated pathway is more capable of inducing increases in ROS through the regulation of antioxidant genes [
43]. E2 can be preferentially oxidised by cytochrome P-450 to produce 2-hydroxyestradiol that reacts with DNA and can be further oxidized to quinone acocmpanied by generation of ROS [
54].
Moreover, we find that the E2-induced ROS contribute to the E2-enhanced radiosensitivity and bystander response of MCF-7 cells (Fig.
4). However, ROS may not be the only signalling factor involved in the bystander response because they can be produced in both irradiated and non-irradiated cells after E2-treatment. We have recently found that nitric oxide (NO) can be produced in irradiated MCF-7 cells. Even when only 1% of cells are targeted, the NO level in the whole cell population can be increased by 19% relative to controls (data not shown). One possibility is that ROS increases not only the E2-enhanced radiosensitivity of MCF-7 cells but also the cellular sensitivity to other toxic factors including NO and its downstream products induced by radiation so that the bystander response of cellular damage can be increased by the E2-treatment. As E2 is an essential factor for the development and growth of breast cancer cells, our finding that E2 increases the radiation-induced bystander effect may have relevance for the future development of radiation-dependent therapies for breast cancer.
Bystander responses have also been observed in breast tumour cells after various chemical treatments. For example, using a co-culture approach, Chhipa and Bhat reported increased bystander cell killing in MCF-7 cells co-culutred with MDA-MB-231 cells which had been pretreated with 5-fluorouracil (5-FU) and this was mediated by the Fas/FasL system [
55]. In another study pre-treatment of breast cells with paclitaxel, leads to increased ROS levels and this could produce increased cell killing in non paclitaxel treated bystander cells [
56].
Conclusion
We report here evidence for radiation-induced bystander responses in breast tumour cells. In MCF-7 cells, the bystander response could be enhanced by treatment with E2 and quenched by the addition of TAM in an ROS dependent manner, neither of which modulated the bystander response in MDA-MD-231 cells. The observation of bystander responses in breast tumour cells may offer new potential targets for radiation-based therapies in the future.
Acknowledgements
We thank Stuart Gilchrist and Bob Sunderland for assistance with irradiations using the Gray Cancer Institute Charged Particle Microbeam. This work was supported by Cancer Research UK [CUK] grant number C1513/A7047, the Gray Cancer Institute, and partly by the Grant (No. 06PJ14012) from the Science & Technology Commission of Shanghai Municipality.
Competing interests
The authors declare that they have no competing interests.
Authors' contributions
CS performed experiments, MF designed microbeam study, KDH and KMP designed study, analysed data. CS wrote the manuscript and KDH and KMP revised manuscript.
