Management of the palatally displaced canine

  • Open Access
  • 01.11.2018
  • Treatment
Erschienen in:

Abstract

The maxillary permanent canine is a common tooth to deviate from its normal path of eruption and become displaced, usually into the roof of the mouth or palate. This article outlines the assessment, diagnosis and potential early management options for a palatally displaced permanent canine tooth (PDC). Some adverse consequences of a PDC are discussed.

Quick reference/description

The maxillary permanent canine is a common tooth to deviate from its normal path of eruption and become displaced, usually into the roof of the mouth or palate. This occurs in about 2% of the population. There are various theories about why this might happen, but one predisposing factor is that the maxillary canine has a long path of eruption.
Early detection of a palatally displaced maxillary permanent canine (PDC), in a young person, is important if interceptive is to be undertaken at the ideal age (10–14 years). The aim of early treatment is to correct the path of eruption and prevent the need for more complicated treatment, namely surgical exposure and prolonged orthodontic alignment.

Assessment and diagnosis

The diagnosis of a PDC is initially undertaken through a clinical examination. Although there can be considerable variation in the chronological age of a young person compared with their dental age, generally, if the permanent canine is not palpable in the buccal sulcus by the age 11 years, then a radiograph should be taken. The distance of the unerupted canine from the occlusal plane, the angulation and in particular the medial position should be assessed.

Management

The management of an unerupted canine will depend on the findings of the clinical and radiographic examination, as well as the expectations, cooperation and age of the patient. The best time to intervene is between the ages of 10 and 14 years (Table 1). Beyond the age the permanent canine would normally be expected to erupt; the outcome of any intervention is likely to be even less predictable.
Table 1
Assessment, diagnosis and management of PDC according to sectors as described by Ericson and Kurol [3]
Assessment
Diagnosis
Management
Sector 1
Angle of less than 21° to the midline
The canine(s) is/are unlikely to be displaced
Monitor eruption
If one canine is high (relative to the occlusal plane) or significantly delayed compared with the other canine or if both canines are delayed relative to the dental age, then consider space creation
The primary canine(s) should exfoliate naturally, but extraction may speed up the eruption of the permanent canine
Sectors 2 and 3
Not palpable
Angle of less than 21° to the midline
The canine(s) is/are probably palatally displaced (check with parallax radiographic views)
Consider space creation or extraction of the primary canine (or both)
Sectors 4 and 5
Not palpable
The canine(s) is/are significantly displaced.
Extraction of the primary canine(s) is unlikely to improve the position of the permanent canine
Surgical exposure and orthodontic alignment will probably be required to align the permanent canine
Maintenance of the primary canine in the medium term could be considered

Overview

See Table 1.

Procedure

Extraction of the primary canine

Several studies have indicated that extraction of the primary canine in young people might lead to improvement in the position of the permanent canine; however, this can be inconsistent and we need more information about when this intervention is likely to help.

Space creation

When the permanent canine is displaced and still has some eruptive potential, then space can be created using transverse expansion of the maxillary arch with rapid maxillary expansion (RME) or anterior–posterior expansion, using a bonded orthodontic appliance or headgear.

Rapid maxillary expansion (RME) (Fig. 1)

Expansion is continued until the palatal cusps of the maxillary posterior teeth are in contact with the buccal cusps of the mandibular posterior teeth.
Fig. 1
a Pretreatment records with insufficient space for the maxillary canines and a displaced upper right permanent canine. b Treatment with RME initially to widen the maxillary arch and create space. Eruption of the canine on the left 7 months after completion of expansion. c Appearance 25 months after expansion. Eruption of canine on the right after 20 months of treatment with fixed appliances. Surgical exposure is not required
Bild vergrößern
RME can be followed by placement of a transpalatal arch (TPA) and extraction of the primary canine if needed.

Bonded orthodontic appliances (Fig. 2)

Space can be created with bonded appliances, accepting an increased overjet and a shift of the upper centerline.
Fig. 2
An example of an impacted upper right canine. 1 cm of space is created using an upper fixed appliance. After that the permanent canine starts erupting. Surgery is not required
Bild vergrößern

Headgear

Cervical pull headgear could be used in patients with moderate crowding and a class II tendency.

Maintenance of the primary tooth

If the permanent canine is considerably displaced from the line of the arch, maintenance of the primary tooth in the medium term, with or without restorative build-up, can be considered.

Advantages and disadvantages of intervention (Table 2)

Pitfalls and complications

A PDC can lead to resorption of adjacent teeth (Fig. 3).
Table 2
Advantages and disadvantages of intervention
Intervention
Advantages
Disadvantages
1. Extraction of the primary canine
Might speed up the eruption of the PDC
Might be effective if the PDC is not too displaced into the palate
Sometimes the first dental procedure the young person has had to undergo
Probably not effective if the PDC is very displaced towards the midline
Can leave a gap in the mouth for a while until the PDC erupts in some patients it is better to preserve the primary canine, rather than subject them to prolong orthodontic treatment
2. Space creation
Might avoid the need
for a dental extraction
Treatment might be prolonged if the PDC takes a while to erupt
Subjects the young person to the usual risks of orthodontic treatment, particularly if the braces are not looked after
3. Maintaining the primary canine
Avoids surgery and potentially lengthy orthodontic treatment
Will require restorative replacement if/when the primary tooth becomes mobile or excessively worn
Fig. 3
a Standard maxillary occlusal radiograph with resorbed lateral and central incisors. b There are no clinical signs of resorption, no discoloration or mobility of any of the incisors
Bild vergrößern
Occasionally, the unerupted canine will not respond to orthodontic forces, either due to a true ankylosis (which is probably rare in the younger patient and with a careful surgical exposure) or to pseudoankylosis, when the unerupted tooth impacts against the root of an adjacent tooth or the buccal plate (Fig. 4).
Fig. 4
a An unerupted maxillary canine that stopped moving in response to orthodontic forces. b The report of the 3D radiographic imaging stated that ‘The upper right canine is impacted against the palatal surface of the root of the adjacent lateral incisor. It is possible to identify a periodontal ligament space around the buccal surface of the root, indicating no ankyloses, however there is an element of uncertainty with visualization of PDL owing to resolution limitations’
Bild vergrößern
Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.
Download
Titel
Management of the palatally displaced canine
Verfasst von
Philip Edward Benson
Elizabeth Anne Graham
Nicola Ann Parkin
Publikationsdatum
01.11.2018
Verlag
Springer International Publishing
Erschienen in
Periodontal and Implant Research / Ausgabe 1/2018
Elektronische ISSN: 2948-2453
DOI
https://doi.org/10.1007/s41894-018-0039-z
1.
Zurück zum Zitat Cobourne MT (ed) (2017) Orthodontic management of the developing dentition, early management of the palatally displaced maxillary permanent canine. Springer, Berlin. https://doi.org/10.1007/978-3-319-54637-7_8 CrossRef
2.
Zurück zum Zitat Ericson S, Kurol J (1986) Longitudinal study and analysis of clinical supervision of maxillary canine eruption. Commun Dent Oral Epidemiol 14(3):172–176CrossRef
3.
Zurück zum Zitat Ericson S, Kurol J (1988) Early treatment of palatally erupting maxillary canines by extraction of the primary canines. Eur J Orthod 10(4):283–295CrossRefPubMed
4.
Zurück zum Zitat Parkin N, Furness S, Shah A, Thind B, Marshman Z, Glenroy G, Dyer F, Benson PE (2012) Extraction of primary (baby) teeth for unerupted palatally displaced permanent canine teeth in children. Cochrane Database Syst Rev 12:CD004621. https://doi.org/10.1002/14651858.CD004621.pub3 CrossRefPubMed
5.
Zurück zum Zitat Chaushu S, Kaczor-Urbanowicz K, Zadurska M, Becker A (2015) Predisposing factors for severe incisor root resorption associated with impacted maxillary canines. Am J Orthod Dentofac Orthop 147(1):52–60. https://doi.org/10.1016/j.ajodo.2014.09.012 CrossRef
